Download LiteratureDigital Yacht ZDIGCOALERT Fume & FireCO Alert Carbon Monoxide Alarm with NMEA 2000The lethal nature of CO means every boat should be protected with a local alarm.  Of course, a typical household alarm could be installed but these have limitations for onboard use.  They utilize an internal battery which will often expire when left for long periods – it’s all too easy to forget to replace with seasonal use on a boat.  What’s more, just a local alarm in a cabin with a crew member sleeping and the vessel underway with the noise of an engine is unlikely to be effective.  CO Alert from Digital Yacht is built for demanding, maritime environments plus has NMEA 2000 integration so alerts will pop up on the boat’s compatible MFD.CO Alert creates a standard NMEA 2000 alert PGN which allows pop-up alarms on compatible MFDs.  (At present, this functionality is best implemented by Garmin).The system can also be expanded further with our NavAlert general-purpose alert and monitoring device and our 4GX/5GX internet access systems.  With this combination, SMS messages can be generated for a CO Alert and sent to a remote phone.Features: DC-powered and UL-listed detector Connects to NMEA 2000 bus Ultra-low power consumption (<25mA) Local loud alarm Test function & continuous checking for system fault NMEA 2000 alerts for activation and fault Multi cabin compatible with multiple detectors (NMEA 2000 instance field programmable) Normalized SKU: ZDIGCOALERTUPC Code: 703791696581Digital Yacht ZDIGCOALERT Literature Download Quick Reference Guide

Safe-T-Alert 62-542-TR-WT-M Fume & Fire62 Series Marine Carbon Monoxide - Flush Mount - White - 12V with Trim RingFeatures: This unit comes with a trim ring to cover existing screw holes and fit newer units into previous installation cutouts. NMMA Listed Component. Space Saving design works in harsh marine environments. Works in extreme temperatures. Only marine CO alarm listed to operational temperatures of -40°F to 158°F. The alarm has consistently held up in the excessive cold and heat due to the high-quality sensor. No False Alarms due to new boat smell, outgassing, or non-hazardous levels of hydrocarbon gases encountered while boating. Interconnect and generator shut-off alarms are available. Low Current Draw(37 mA). An innovative micro-current circuit saves battery power for the boater. Alarm Mute with Auto Reset. With a press of a button, the mute circuit will temporarily silence the alarm while the boater ventilates the cabin. The alarm will reactivate if it still senses dangerous levels of CO. End of Life Signal alerts boater to replace the alarm after 5 years of service. Memory Scan. Retains the CO level that activated the alarm. After ventilation, it is impossible to know what the CO level was unless the detector has memory. The rapid recovery sensor resets when silenced or reactivates the alarm if dangerous levels of CO remain. Specifications: Conforms To ANSI / UL STD 2034* * Testing Laboratory: ETL/Intertek Alarm Point: 400 PPM 4-15 Minutes Low voltage power warning at 7 Volts Power Supply and Current Draw: 37 mA @ 13.8 VDC Operational Range: 13.8 Volts +/-15% Low voltage power warning at 7 Volts Operating Temperature: -40°F to +158°F Case Size: 4.5″W x 3.25″H x 1.25″D Normalized SKU: 62542TRWTM

Safe-T-Alert FX-4-MARINE Fume & Fire FX-4 Marine Surface Mount Slim Vertical Carbon Monoxide Alarm Surface Mount Low Voltage Hard Wired Alarm. Conforms To ANSI / UL STD 2034 © Marine. Meets ABYC A-24. NMMA Listed Component. Most Reliable. Boats DC electrical system or marine grade batteries supply power to the alarm. No missing or dead batteries to replace. Proven Sensing Technology. Prevents nuisance alarms which could lead to confusion and disconnected detectors. Advanced Technology. Alarm Mute button with advanced technology that silences alarm while boat is ventilated. Rapid recovery sensor resets when silenced or reactivates alarm if dangerous levels of CO remain. Loud. 85 dB alarm alerts you to CO danger. Operating Specifications: Conforms To ANSI / UL STD 2034, Testing Laboratory: ETL/Intertek, Alarm Point: 400 PPM 4-15 Minutes, Low voltage power warning at 8 Volts, Power Supply and Current Draw: 37 mA @ 13.8 VDC, Operational Range: 13.8 Volts +/-15%, Operating Temperature: -40°F to +158°F, Case Size: 2.5?W x 3.5?H x 1.25?D © Mounting Bracket .25?D Normalized SKU: FX4MARINEUPC Code: 715456625478

Safe-T-Alert 62-542-WT-MARINE-TR Fume & Fire 62 Series Marine with Trim Ring Marine Mini Carbon Monoxide Alarm with Trim Ring. This unit comes with a trim ring to cover existing screw holes and fit newer units into previous installation cutouts. NMMA Listed Component. Works in harsh marine environments and extreme temperatures. This is the only marine CO alarm listed to operational temperatures of -40°F to 158°F. Alarm has consistently held up in the excessive cold and heat due to high quality sensor. No False Alarms due to new boat smell, outgassing or non-hazardous levels of hydrocarbon gases encountered while boating. Interconnect and generator shut off alarms available. Alarm Mute with Auto Reset. With a press of a button, the mute circuit will temporarily silence the alarm while the boater ventilates the cabin. Alarm will reactivate if it still senses dangerous levels of CO. End of Life Signal alerts boater to replace the alarm after 5 years of service. Memory Scan. Retains the CO level that activated the alarm. After ventilation, it is impossible to know what the CO level was unless the detector has memory. Rapid recovery sensor resets when silenced or reactivates alarm if dangerous levels of CO remain. Operating Specifications: Conforms To ANSI / UL STD 2034, Testing Laboratory: ETL/Intertek, Alarm Point: 400 PPM 4-15 Minutes, Low voltage power warning at 7 Volts, Power Supply and Current Draw: 37 mA at 13.8 VDC, Operational Range: 13.8 Volts +/-15%, Low voltage power warning at 7 Volts Normalized SKU: 62542WTMARINETRUPC Code: 715456632483

Xintex-Fireboy OMSD-01-DB-R Fume & FireOptical Smoke Detector with BaseOptical smoke detectors have consistently been recognized as suitable detectors for general use. They are regarded as particularly suitable for smoldering fires and escape routes. This smoke detector is also designed to significantly reduce the incidence of false alarms through over-sensitivity to transient phenomena.Features: Recommended for use as general-purpose smoke detectors for early warning of fires in most areas Works well in black as well as in white smoke Compensation for slow changes in sensitivity Extra confirmation of smoke before an alarm signal is given Specifications: Sampling Frequency: Once every four seconds  Operating Voltage: 8.5 V dc to 33 V dc  Supply Wiring: Two wire supply, polarity sensitive  Power-up Time: < 20 seconds  Minimum ‘Detector Active’ Voltage: 6 V Minimum Holding Current: 8 mA  Minimum Voltage to Light Alarm LED: 5 V  Alarm Reset Time: One second  Alarm Indicator: Integral indicator with 360º visibility  Operating & Storage Temperature: -40ºC to +70ºC Humidity (no condensation or icing): 0% to 98% RH Operation: Optical Smoke Detectors work on the well-established light scatter principle The remarkable optical design of this Smoke Detector enables it to respond to a wide spectrum of fires The sensing chamber contains an optical sensor that measures back-scattered light as well as the more usual forward-scattered light  The detector is calibrated so that it is highly reliable in detecting fires but is much less likely to generate false alarms The stability of the detector-high reliability, low false alarm rate is further increased by the use of algorithms to decide when the detector should change to the alarm state  Removes the likelihood of a detector producing an alarm as a result of smoke from smoking materials or another non-fire source Normalized SKU: OMSD01DBRUPC Code: 619749321095

Xintex-Fireboy OMHD-04-DB-R Fume & FireRate-of-Rise Heat Detector with BaseThe Fireboy-Xintex Heat Detector uses a single thermistor to sense the air temperature around the detector. This heat detector was designed to detect how fast the temperature is increasing.Features: 163°F Rate-of-Rise Heat Detector Housing: White flame-retardant polycarbonate Terminals: Nickel-plated stainless steel Ideal in environments that are dirty or smoky Unaffected by wind or atmospheric pressure Remote test feature Specifications: Detection Principle: Measurement of heat using a thermistor Sampling Frequency: Once every four seconds Supply Voltage: 8.5 V dc to 33 V dc Supply Wiring: Two wire supply, polarity sensitive Power-up Time: < 20 seconds Minimum: ‘detector active’ voltage: 6 V Holding Voltage: 5 V - 33 V Minimum Holding Current: 8 mA  Minimum Voltage to Light Alarm LED: 5 V  Alarm Reset Voltage: < 1 V  Alarm Reset Time: One second  Alarm Indicator: Integral indicator with 360º visibility Operating & Storage Temperature: -40ºC to +70ºC Operation: Open-web casing that enables air to flow freely across a thermistor which measures the air temperature every two seconds  A microprocessor stores the temperatures and compares them with pre-set values to determine whether a fixed upper limit - the alarm level - has been reached Detectors the microprocessor uses algorithms to determine how fast the temperature is increasing Normalized SKU: OMHD04DBRUPC Code: 619749321088

Xintex-Fireboy 90107 Fume & FireSystem Ready Panel Warning Light The green warning L.E.D. provides constant monitoring of the fire suppression system when the ignition switch is On.  Complies with U.S. Coast Guard requirements for system approval.This 2" round indicator light has an adhesive back aluminum plate for easy panel mounting and requires a 5/16" hole for wire routing.Standard with all pre-engineered fire extinguishing systems.Compatible With:MA2, CG2 and GA suppression systems *Sold as an Individual  Normalized SKU: 90107
