Lowrance 000-15509-001 FishfindersHOOK Reveal 5 Combo with 50/200 HDI Transom Mount & Navionics+ ChartFrom the world’s best-selling series of fishfinders comes HOOK Reveal, a fishfinder/chartplotter with one of our most popular features – FishReveal™. This powerful fishfinding tool combines the proven target identification of Lowrance CHIRP sonar with the high-resolution images of bottom detail and structure from DownScan Imaging™. That gives you the ultimate fishing view, allowing you to target fish and get the best view of how they are relating to structure without the need for a CHIRP-DownScan Imaging™ splitscreen display.Designed to make the most of your time on the water, HOOK Reveal ensures you get the best sonar image every time with Autotuning Sonar, a unique feature that automatically adjusts sonar settings as fishing conditions change. Our 83/200 and 50/200 HDI models provide improved sonar performance in deep water, plus with our TripleShot models, you can cover more water in less time with double the sonar coverage of other fishfinders.HOOK Reveal comes with C-MAP chart compatibility to get you on the fish, as well as Genesis Live real-time mapping. Map uncharted areas – down to ½-foot contours – with Genesis Live.Features: FishReveal™ Genesis Live Real-Time Mapping Autotuning sonar 50/200 HDI transducer with Low/High CHIRP and DownScan Imaging™ Preloaded US/Canada Navionics+ chart SolarMAX™ Display Fish-finding color palettes Optimized keypad with one-touch access to key features Mapping options include C-MAP, C-MAP Genesis, Navionics® and more microSD card slot Easy front-dash or gimbal-bracket mount Improved sonar performance in deep water 50/200 HDI Transducer 000-15639-001 HDI Skimmer® transducer 50/200 / 455/800kHz for Hook² / Hook Reveal, with built in temp. Includes mounting bracket and hardware.  Cable Length 6 m (20 ft). Connector: 8 pin push fit.Hybrid Dual Imaging™ (HDI) transducer (50/200/455/800) - The power of two award-winning technologies -- Broadband Sounder PLUS Exclusive DownScan Imaging™ -- combined to provide the best-possible view beneath your boat.Comes with: Hook Reveal 5 Display, Power cord, mounting Bracket, HDI 50/200 Transom mount Transducer and Navionics+ Chart Specifications:Transducer Included = Yes Touchscreen = No Screen Size = 5" Included Transducer = 000-15639-001 Cartography Brand = Navionics/C-Map/LowranceNormalized SKU: 00015509001UPC Code: 9420064114443

Watch VideoSimrad 000-15624-001 FishfindersNSS12 evo3 Radar Bundle with HALO20+ C-MAPNSS12 evo3This high-definition 12-inch display delivers a big-picture view of high-detail, C-MAP US Enhanced inland and coastal charts, Radar, Active Imaging Sonar, and more. Perfect for larger powerboats and sportfishing center consoles, NSS evo3 has integrated wireless connectivity and an HDMI out, allowing you to mirror your display to your smartphone, tablet, or an on-board TV. Navigate expertlyWhether you are cruising or searching for key fishing areas, the preloaded C-MAP US Enhanced chart in NSS evo3 will get you there with precision. The high-detail, built-in chart makes navigation easy with 1-foot contours on nearly 4,000 lakes, plus the C-MAP coastal charts boaters have relied on for years. Make the most of your boatNavigate, find fish, and take total control of your on-water experience with NSS evo3. SolarMAX™ IPS displays  offer exceptional clarity and ultra-wide viewing angles, even in direct sunlight, while an intuitive all-weather touchscreen and a keypad with rotary dial offer total control in any conditions. Built-in echosounder support lets you cruise confidently with ForwardScan sonar, or reveal the ultimate fishing spots with Active Imaging 3-in-1 with CHIRP, SideScan and DownScan Imaging™. Register your chartplotter, get faster technical support, download software updates and connect NSS evo3 to your smartphone or tablet with integrated wireless connectivity.Touchscreen plus keypad for intuitive and reliable controlNSS evo3 displays let you take control your way. Switch seamlessly between intuitive touchscreen control with multi-touch gestures, perfect for cruising on a flat day, and a built-in keypad with rotary control dial for fishing and boating adventures. Control every display function by either touch or keypad, giving you total flexibility to use whatever controls best suit the situation.Chartplotter with built-in GPS makes navigation easyEvery NSS evo3 display is a full-featured chartplotter navigation display with a built-in GPS receiver that eliminates the need for an external antenna on many boats. Choose from a wide range of charts to find the best coverage for your favorite boating locations, anywhere in the world. Make plotting a route to your destination as simple as in-car navigation with C-MAP Easy Routing.Built-in echosounder supports fishing and safer cruisingA built-in echosounder support enables many sportfishing and cruising activities – just add your choice of sonar transducer. Active Imaging™ provides picture-like views of fish holding structure, while award-winning ForwardScan® sonar offers a safer cruising experience with a clear view of the bottom ahead. CHIRP sonar provides reliable bottom-tracking and fish-finding performance, including support for dual-channel CHIRP transducers to deliver simultaneous coverage of multiple depth ranges. Dual transducer ports let you connect multiple transducers to a single display.Simple networking connects you to a wide range of accessoriesIndustry-standard connectivity makes it easy to create multi-display systems and link your displays to all of your on-board electronics. Monitor your boat’s engines and fuel efficiency, control your on-board sound system, and much more. Expand your system with Simrad modules and accessories: fish smarter with game-changing StructureScan® 3D imaging, see further with legendary Halo™ Pulse Compression radar, and free your hands from the wheel with a fully integrated Simrad autopilot.Simple networking connects you to a wide range of accessoriesIndustry-standard connectivity makes it easy to create multi-display systems and link your displays to all of your on-board electronics. Monitor your boat’s engines and fuel efficiency, control your on-board sound system, and much more. Expand your system with Simrad modules and accessories: fish smarter with game-changing StructureScan® 3D imaging, see further with legendary Halo™ Pulse Compression radar, and free your hands from the wheel with a fully integrated Simrad autopilot.SolarMAX™ IPS displays ensure clear views in any conditionsGet a clear view under any lighting conditions with SolarMAX™ IPS   technology, which keeps everything in view with ultra-wide viewing angles – visible even through polarized sunglasses. These all-weather screens have been engineered to withstand the heat of the summer sun, and are optically bonded to prevent condensation or fogging within the display. It’s easy to monitor and control all of your on-board electronics with simple menus and customizable split-screen layouts.Wireless connectivity to your smartphone or tabletMirror your display to compatible iOS and Android devices, and enjoy access to charts, radar, sonar, engine data, and more from anywhere on board. Check charts and weather radar to plot your next move from the saloon, or keep your fish-finding sonar display beside you while you cast your line. Wireless connectivity also enables easy online software upgrades through any internet hotspot, giving you access to the latest features and accessory support.Features: SolarMAX IPS display with extreme viewing angles; viewable through polarized sunglasses Preloaded, high-detail C-MAP US Enhanced inland and coastal charts Full operation via touchscreen or keypad controls Touchscreen control of sonar, radar, autopilot and accessories Industry-standard connectivity to engines, sound systems and more Automatic routing support, plus easy trip planning with TripIntel Flexible installation with low-profile flush mount or bracket mount options HALO 20+ Radar for greater situational awarenessBring radar capabilities to your boat with this compact and easy-to-install dome radar system. The HALO Radar dome series detects targets from right off the bow and up to 48 nautical miles away. Use HALO to cruise confidently through crowded harbors, navigate safely in poor visibility, and keep an eye on distant storm cells. The HALO20+ Radar offer an almost real-time view with industry-first 60 RPM operation at close range.  Specifications:Transducer Included = No Touchscreen = Yes Screen Size = 12" Cartography Brand = Navionics/C-Map/Lowrance Array Size (Inches) = 20"Normalized SKU: 00015624001UPC Code: 9420064115778Simrad 000-15624-001 Video

Download LiteratureGarmin 010-02341-00 FishfindersECHOMAP™ UHD 92sv without TransducerJoin the Club. Find More Fish.The sunlight-readable 9” touchscreen chartplotter features a quick-release bail mount, and the transducer bundle adds Ultra High-Definition scanning sonar and CHIRP traditional sonar.Features: See below and around your boat in incredible detail with optional transducer  Navigate any waters with optional charts and maps  Share data with other devices on your network (7” and 9” models only)  Manage your marine experience from nearly anywhere  Control the most powerful trolling motor available  Create your own maps on the fly and tailor them to fit your needs Sonar SupportThis chartplotter supports a variety of Garmin transducers (sold separately), including the Panoptix LiveScope™ scanning sonar system, which lets you see all around your boat in real time. Optional Charts and MapsExperience unparalleled coverage and detail with support for optional BlueChart® g3 Vision coastal charts featuring integrated Garmin and Navionics® content. Quickdraw ContoursCreate personalized fishing maps on-screen with 1’ contours. Keep the data to yourself, or share it with the Quickdraw Community on Garmin Connect™. Network CapableIf you have multiple compatible ECHOMAP UHD or ECHOMAP Ultra devices on your boat, you can share information — such as sonar, user data and charts — among them (7” and 9” models only). NMEA 2000® and NMEA 0183 NetworksConnect to autopilots, digital switching, weather, FUSION-Link™ audio system, media, VHF, AIS and more from one screen. ActiveCaptain® AppBuilt-in Wi-Fi® connectivity pairs with the free all-in-one mobile app for access to the OneChart™ feature, smart notifications1, software updates, Garmin Quickdraw™ Community data and more. Force™ Trolling Motor CompatibilityTake control of the most powerful and efficient trolling motor available2, route it to waypoints, follow tracks and more from the screen of your chartplotter. In The Box ECHOMAP UHD 92sv with worldwide basemap 8-pin transducer to 12-pin sounder adapter cable Power/data cable Tilt mount with quick release cradle Flush mount Protective cover Hardware Documentation 1 When paired with a compatible smartphone2 In compliance with ISO standard 13342Wi-Fi is a registered trademark of the Wi-Fi Alliance.WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Normalized SKU: 0100234100UPC Code: 753759241612Garmin 010-02341-00 Literature Download Owners Manual

Garmin 010-02342-01 FishfindersECHOMAP™ UHD 93sv US LakeVü g3 with GT54UHD-TM Transducer Find more fish using the ECHOMAP™ UHD 93sv combo with a bright, sunlight-readable 9” touchscreen with keyed assist. The optional GT54 transducer provides Ultra High-Definition ClearVü and SideVü scanning sonars, so you get crystal-clear images of what is around and below your boat, and Garmin high wide CHIRP traditional sonar delivers remarkable target separation. Preloaded LakeVü g3 inland maps with integrated Navionics® data cover more than 17,000 lakes with up to 1’ contours. It features a quick-release bail mount, making it easy to remove and take with you. NMEA 2000® and NMEA 0183 network support provides you with engine data, sensor connection, autopilot integration and more. ECHOMAP™ UHD 93sv is even compatible with the Force™ trolling motor for full control of the motor from the screen plus the ability to route to waypoints, follow tracks and more.Features: Bright, sunlight-readable 9” touchscreen with keyed assist Optional GT54 transducer for Ultra High-Definition ClearVü and Ultra High-Definition SideVü scanning sonars and Garmin high wide CHIRP traditional sonar Preloaded LakeVü g3 inland maps with integrated Navionics® data cover more than 17,000 lakes with up to 1’ contours Supports Panoptix™ all-seeing sonar, including Panoptix LiveScope™ sonar Sonar sharing capabilities with other ECHOMAP™ Plus, ECHOMAP UHD and ECHOMAP Ultra units NMEA 2000® and NMEA 0183 network support for autopilot and engine data Quick-release bail mount for fast and easy mobility Compatible with Force™ trolling motor for full control of the motor from the screen plus the ability to route to waypoints, follow tracks and more Included TransducerThis chartplotter comes with a GT24 transducer for Ultra High-Definition ClearVü scanning sonar, which shows you a crystal-clear image below your boat. Plus, you get Garmin high wide CHIRP traditional sonar for remarkable target separation. Sonar SupportThis chartplotter supports a variety of Garmin transducers (sold separately), including the Panoptix LiveScope™ scanning sonar system, which lets you see all around your boat in real time.Preloaded ChartsExperience unparalleled coverage and detail with preloaded LakeVü g3 inland maps featuring integrated Navionics® data that covers more than 17,000 lakes with up to 1’ contours. Quickdraw ContoursCreate personalized fishing maps on-screen with 1’ contours. Keep the data to yourself, or share it with the Quickdraw Community on Garmin Connect™. NMEA 2000® & NMEA0183 NetworksConnect to autopilots, digital switching, weather, FUSION-Link™ audio system, media, VHF, AIS and more from one screen. ActiveCaptain® AppBuilt-in Wi-Fi® connectivity pairs with the free all-in-one mobile app for access to the OneChart™ feature, smart notifications1, software updates, Garmin Quickdraw™ Community data and more. Network CapableIf you have multiple compatible ECHOMAP UHD or ECHOMAP Ultra devices on your boat, you can share information — such as sonar, user data and charts — among them (7” and 9” models only). Force™ Trolling Motor CapabilityTake control of the most powerful and efficient trolling motor available2, route it to waypoints, follow tracks and more from the screen of your chartplotter.Connections Garmin Marine Network Ports: 1 NMEA 2000 Compatible: Yes Transducer Pin Numbers: 12 NMEA 0183 Input Ports: 1 NMEA 0183 Output Ports: 1 Video Input Ports: None Video Output Ports: None Wireless Connectivity: Yes In The Box ECHOMAP UHD 93sv with LakeVü g3 for U.S. GT54UHD-TM transducer Power/data cable Tilt mount with quick release cradle Flush mount Protective cover Hardware Documentation 1 When paired with a compatible smartphone2 In compliance with ISO standard 13342Wi-Fi is a registered trademark of the Wi-Fi Alliance.WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Normalized SKU: 0100234201UPC Code: 753759241643

Garmin 010-02342-00 FishfindersECHOMAP™ UHD 93sv US LakeVü g3 without TransducerFind more fish using the ECHOMAP™ UHD 93sv combo with a bright, sunlight-readable 9” touchscreen with keyed assist. The optional GT54 transducer provides Ultra High-Definition ClearVü and SideVü scanning sonars, so you get crystal-clear images of what is around and below your boat, and Garmin high wide CHIRP traditional sonar delivers remarkable target separation. Preloaded LakeVü g3 inland maps with integrated Navionics® data cover more than 17,000 lakes with up to 1’ contours. It features a quick-release bail mount, making it easy to remove and take with you. NMEA 2000® and NMEA 0183 network support provides you with engine data, sensor connection, autopilot integration and more. ECHOMAP™ UHD 93sv is even compatible with the Force™ trolling motor for full control of the motor from the screen plus the ability to route to waypoints, follow tracks and more.Features: Bright, sunlight-readable 9” touchscreen with keyed assist Optional GT54 transducer for Ultra High-Definition ClearVü and Ultra High-Definition SideVü scanning sonars and Garmin high wide CHIRP traditional sonar Preloaded LakeVü g3 inland maps with integrated Navionics® data cover more than 17,000 lakes with up to 1’ contours Supports Panoptix™ all-seeing sonar, including Panoptix LiveScope™ sonar Sonar sharing capabilities with other ECHOMAP™ Plus, ECHOMAP UHD and ECHOMAP Ultra units NMEA 2000® and NMEA 0183 network support for autopilot and engine data Quick-release bail mount for fast and easy mobility Compatible with Force™ trolling motor for full control of the motor from the screen plus the ability to route to waypoints, follow tracks and more waypoints, follow tracks and more Optional Transducer BundleSelect the transducer bundle to add a GT54 transducer for Ultra High-Definition ClearVü and SideVü scanning sonars, which show you crystal-clear images below and around your boat. Plus, you get Garmin high wide CHIRP traditional sonar for remarkable target separation.Sonar SupportThis chartplotter supports a variety of Garmin transducers (sold separately), including the Panoptix LiveScope™ scanning sonar system, which lets you see all around your boat in real time.Preloaded MappingExperience unparalleled coverage and detail with preloaded LakeVü g3 inland maps featuring integrated Navionics® data that covers more than 17,000 lakes with up to 1’ contours. Quickdraw ContoursCreate personalized fishing maps on-screen with 1’ contours. Keep the data to yourself, or share it with the Quickdraw Community on Garmin Connect™. NMEA 2000® & NMEA0183 NetworksConnect to autopilots, digital switching, weather, FUSION-Link™ audio system, media, VHF, AIS and more from one screen. ActiveCaptain® AppBuilt-in Wi-Fi® connectivity pairs with the free all-in-one mobile app for access to the OneChart™ feature, smart notifications1, software updates, Garmin Quickdraw™ Community data and more. Network CapableIf you have multiple compatible ECHOMAP UHD or ECHOMAP Ultra devices on your boat, you can share information — such as sonar, user data and charts — among them (7” and 9” models only). Force™ Trolling Motor CapabilityTake control of the most powerful and efficient trolling motor available2, route it to waypoints, follow tracks and more from the screen of your chartplotter.Connections Garmin Marine Network Ports: 1 NMEA 2000 Compatible: Yes Transducer Pin Numbers: 12 NMEA 0183 Input Ports: 1 NMEA 0183 Output Ports: 1 Video Input Ports: None Video Output Ports: None Wireless Connectivity: Yes In The Box ECHOMAP UHD 93sv with LakeVü g3 for U.S. Power/data cable Tilt mount with quick release cradle Flush mount Protective cover Hardware Documentation 1 When paired with a compatible smartphone2 In compliance with ISO standard 13342Wi-Fi is a registered trademark of the Wi-Fi Alliance.WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Normalized SKU: 0100234200UPC Code: 753759241636

Garmin 010-02338-01 FishfindersECHOMAP™ UHD 73sv LakeVü g3 with GT54UHD-TM TransducerFind more fish using the ECHOMAP™ UHD 73sv combo with a bright, sunlight-readable 7” touchscreen with keyed assist. The optional GT54 transducer provides Ultra High-Definition ClearVü and SideVü scanning sonars, so you get crystal-clear images of what is around and below your boat, and Garmin high wide CHIRP traditional sonar delivers remarkable target separation. Preloaded LakeVü g3 inland maps with integrated Navionics® data cover more than 17,000 lakes with up to 1’ contours. It features a quick-release bail mount, making it easy to remove and take with you.  NMEA 2000® and NMEA 0183 network support provides you with engine data, sensor connection, autopilot integration and more. ECHOMAP™ UHD 73sv is even compatible with the Force™ trolling motor for full control of the motor from the screen plus the ability to route to waypoints, follow tracks and more.Features: Bright, sunlight-readable 7” touchscreen with keyed assist Optional GT54 transducer for Ultra High-Definition ClearVü and Ultra High-Definition SideVü scanning sonars and Garmin high wide CHIRP traditional sonar Preloaded LakeVü g3 inland maps with integrated Navionics® data cover more than 17,000 lakes with up to 1’ contours Supports Panoptix™ all-seeing sonar, including Panoptix LiveScope™ sonar Sonar sharing capabilities with other ECHOMAP™ Plus, ECHOMAP UHD and ECHOMAP Ultra units NMEA 2000® and NMEA 0183 network support for autopilot and engine data Quick-release bail mount for fast and easy mobility Compatible with Force™ trolling motor for full control of the motor from the screen plus the ability to route to waypoints, follow tracks and more Included TransducerThis chartplotter comes with a GT24 transducer for Ultra High-Definition ClearVü scanning sonar, which shows you a crystal-clear image below your boat. Plus, you get Garmin high wide CHIRP traditional sonar for remarkable target separation. Sonar SupportThis chartplotter supports a variety of Garmin transducers (sold separately), including the Panoptix LiveScope™ scanning sonar system, which lets you see all around your boat in real time.Preloaded ChartsExperience unparalleled coverage and detail with preloaded LakeVü g3 inland maps featuring integrated Navionics® data that covers more than 17,000 lakes with up to 1’ contours. Quickdraw ContoursCreate personalized fishing maps on-screen with 1’ contours. Keep the data to yourself, or share it with the Quickdraw Community on Garmin Connect™. NMEA 2000® & NMEA 0183 NetworksConnect to autopilots, digital switching, weather, FUSION-Link™ audio system, media, VHF, AIS and more from one screen. ActiveCaptain® AppBuilt-in Wi-Fi® connectivity pairs with the free all-in-one mobile app for access to the OneChart™ feature, smart notifications1, software updates, Garmin Quickdraw™ Community data and more. Network CapableIf you have multiple compatible ECHOMAP UHD or ECHOMAP Ultra devices on your boat, you can share information — such as sonar, user data and charts — among them (7” and 9” models only). Force™ Trolling Motor CapabilityTake control of the most powerful and efficient trolling motor available2, route it to waypoints, follow tracks and more from the screen of your chartplotter.Connections Garmin Marine Network Ports: 1 NMEA 2000 Compatible: Yes Transducer Pin Numbers: 12 NMEA 0183 Input Ports: 1 NMEA 0183 Output Ports: 1 Video Input Ports: None Video Output Ports: None Wireless Connectivity: Yes In The Box ECHOMAP UHD 73sv with BlueChart g3 for U.S. GT54UHD-TM transducer Power/data cable Tilt mount with quick release cradle Flush mount Protective cover Hardware Documentation 1 When paired with a compatible smartphone2 In compliance with ISO standard 13342Wi-Fi is a registered trademark of the Wi-Fi Alliance.WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Normalized SKU: 0100233801UPC Code: 753759241575

Garmin 010-02322-03 FishfindersGPSMAP® 1242xsv Plus Touchscreen GPS/Fishfinder ComboSideVü, ClearVü and Traditional CHIRP Sonar with MappingAdvanced navigation. Ultimate integration. This compact 12” GPSMAP® 1242xsv Touch Plus touchscreen combo seamlessly integrates into your Garmin marine system for full control of your connected helm. It supports 1 kW CHIRP traditional sonar, ClearVü and SideVü scanning sonars and Panoptix™ all-seeing sonar, including Panoptix LiveScope™ sonar. Preloaded BlueChart® g3 coastal charts and LakeVü g3 inland maps give you the best of Garmin and Navionics® data and Auto Guidance* technology. Share maps, user data, radar and IP cameras among multiple units using the Garmin Marine Network. NMEA 2000® and NMEA 0183 networking connect you to autopilots, digital switching, weather, media, VHF, AIS and other sensors. Plus, this unit uses ANT® technology to pair with compatible Garmin devices, such as marine watches, transducers, wireless remote controls and more. It also includes built-in Garmin SailAssist™ features, such as laylines, race features, set and drift, wind data and more. Add the free all-in-one ActiveCaptain® app to manage your marine experience from nearly anywhere.Features: Bright, sunlight-readable 12” intuitive touchscreen is easy to use in any environment Built-in 1 kW CHIRP traditional and ClearVü scanning sonar (transducers sold separately) Supports Panoptix™ all-seeing sonar, including Panoptix LiveScope™ sonar J1939 engine connectivity for easy integration with engines, such as Yamaha, and our exclusive OneHelm™ feature for connecting to third-party devices, such as EmpirBus™ digital switching Easily build your marine system — from sonar and autopilots to cameras and multimedia — using NMEA 2000® and NMEA 0183 network connectivity and the Garmin Marine Network Preloaded BlueChart® g3 coastal charts and LakeVü g3 inland maps with integrated Navionics® data and Auto Guidance* technology Built-in Garmin SailAssist™ features, including laylines, race features, set and drift, wind data and more Add free all-in-one ActiveCaptain® app to manage your marine experience from nearly anywhere Integrated ANT® technology support for use with quatix® marine watches, gWind™ Wireless 2 transducer, GNX™ Wind marine instrument and wireless remote controls Traditional & Scanning SonarsGet built-in support for 1 kW CHIRP traditional sonar for superior target separation and ClearVü and SideVü scanning sonars to see up to 1,000’ below and around your boat at 260 kHz (transducer sold separately). Panoptix™ Sonar SupportPair with Panoptix or Panoptix LiveScope™ easy-to-interpret live sonar (transducer sold separately) to see all around your boat in real time. Preloaded MappingExperience unparalleled coverage and detail with preloaded BlueChart® g3 coastal charts and LakeVü g3 inland maps featuring integrated Garmin and Navionics® content and Auto Guidance1 technology. Optional BlueChart® g3 Vision® ChartsUpgrade to our reliable premium charts, which add even more industry leading features, such as high-resolution relief shading, to help you on each trip. Garmin Marine NetworkIf you have multiple Garmin devices on your boat, you can share information — such as maps, user data, radar and IP cameras — among them. NMEA 2000® & NMEA0183 NetworksConnect to autopilots, digital switching, weather, FUSION-Link™ audio system, media, VHF, AIS and more from one screen. ActiveCaptain® AppBuilt-in Wi-Fi® connectivity pairs with the free all-in-one mobile app for access to the OneChart™ feature, smart notifications2, software updates, Garmin Helm, Garmin Quickdraw™ Community data and more. Integrated ANT® TechnologyConnect with some of your favorite devices, such as quatix® marine watches, gWind™ Wireless 2 transducers, GNX™ Wind marine instruments and wireless remote controls. JI939 ConnectivityNow you can connect your chartplotter to different kinds of engines, including Yamaha engines. OneHelm™ FeatureThis exclusive feature brings together all the operations and capabilities of third-party devices, such as EmpirBus™ digital switching, on one screen.In The Box GPSMAP 1242xsv Plus chartplotter Power cable 8-pin transducer to 12-pin sonar adapter cable NMEA 2000 T-connector NMEA 2000 drop cable (2 m) Bail mount kit with knobs Flush mount kit with gasket Protective cover Trim piece snap covers Documentation Connections Garmin Marine Network™ Ports: 2 Transducer Ports: 1 (12 Pin) NMEA 2000® Port: 1 NMEA 0183 Input Ports: 1 NMEA 0183 Output Ports: 1 J1939 Port: 1 Video Input Ports:  1 BNC Video Output Ports: 1 HDMI Wireless Connectivity: Yes 1 Auto Guidance is for planning purposes only and does not replace safe navigation operations2 When paired with a compatible smartphoneWi-Fi is a registered trademark of the Wi-Fi Alliance.WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Normalized SKU: 0100232203UPC Code: 753759240875

Garmin 010-02321-03 FishfindersGPSMAP® 942xs Plus Touchscreen GPS/Fishfinder ComboClearVü and Traditional CHIRP Sonar with MappingAdvanced navigation. Ultimate integration. This compact 9” GPSMAP® 942xsv Plus touchscreen combo features enhanced map drawing and seamlessly integrates into your Garmin marine system for full control of your connected helm. It supports 1 kW CHIRP traditional sonar, ClearVü scanning sonar and Panoptix™ all-seeing sonar, including Panoptix LiveScope™ sonar. Preloaded BlueChart® g3 coastal charts and LakeVü g3 inland maps give you the best of Garmin and Navionics® data and Auto Guidance* technology. Share maps, user data, radar and IP cameras among multiple units using the Garmin Marine Network. NMEA 2000® and NMEA 0183 networking connect you to autopilots, digital switching, weather, media, VHF, AIS and other sensors. Plus, this unit uses ANT® technology to pair with compatible Garmin devices, such as marine watches, transducers, wireless remote controls and more. It also includes built-in Garmin SailAssist™ features, such as laylines, race features, set and drift, wind data and more.*Auto Guidance is for planning purposes only and does not replace safe navigation operationsFeatures: Bright, sunlight-readable 9” intuitive touchscreen combo with enhanced map drawing Built-in 1 kW CHIRP traditional and ClearVü scanning sonar plus CHIRP DownVü scanning sonar (transducers sold separately) Supports Panoptix™ all-seeing sonar, including Panoptix LiveScope™ sonar J1939 engine connectivity for easy integration with engines, such as Yamaha, and our exclusive OneHelm™ feature for connecting to third-party devices, such as EmpirBus™ digital switching Easily build your marine system — from sonar and autopilots to cameras and multimedia — using NMEA 2000® and NMEA 0183 network connectivity and the Garmin Marine Network Preloaded BlueChart® g3 coastal charts and LakeVü g3 inland maps with integrated Navionics® data and Auto Guidance1 technology Built-in Garmin SailAssist™ features, including laylines, race features, set and drift, wind data a GPSMAP 942xs Plus chartplotter Power cable Bail mount with knobs Flush mount kit with gasket Protective cover Trim piece snap covers Documentation nd more Traditional & Scanning SonarsGet built-in support for 1 kW CHIRP traditional sonar for superior target separation and ClearVü scanning sonar to see up to 1,000’ below your boat at 260 kHz (transducer sold separately). Panoptix™ Sonar SupportPair with Panoptix or Panoptix LiveScope™ easy-to-interpret live sonar (transducer sold separately) to see all around your boat in real time. Preloaded MappingExperience unparalleled coverage and detail with preloaded BlueChart® g3 coastal charts and LakeVü g3 inland maps featuring integrated Garmin and Navionics® content and Auto Guidance1 technology. Optional BlueChart® g3 Vision® ChartsUpgrade to our reliable premium charts, which add even more industry leading features, such as high-resolution relief shading, to help you on each trip.Garmin Marine NetworkIf you have multiple Garmin devices on your boat, you can share information — such as maps, user data, radar and IP cameras — among them. NMEA 2000® & NMEA0183 NetworksConnect to autopilots, digital switching, weather, FUSION-Link™ audio system, media, VHF, AIS and more from one screen. ActiveCaptain® AppBuilt-in Wi-Fi® connectivity pairs with the free all-in-one mobile app for access to the OneChart™ feature, smart notifications2, software updates, Garmin Helm, Garmin Quickdraw™ Community data and more. Integrated ANT® TechnologyConnect with some of your favorite devices, such as quatix® marine watches, gWind™ Wireless 2 transducers, GNX™ Wind marine instruments and wireless remote controls. JI939 ConnectivityNow you can connect your chartplotter to different kinds of engines, including Yamaha engines. OneHelm™ FeatureThis exclusive feature brings together all the operations and capabilities of third-party devices, such as EmpirBus™ digital switching, on one screen.In The Box GPSMAP 942xs Plus chartplotter Power cable Bail mount with knobs Flush mount kit with gasket Protective cover Trim piece snap covers Documentation 1 Auto Guidance is for planning purposes only and does not replace safe navigation operations2 When paired with a compatible smartphoneWi-Fi is a registered trademark of the Wi-Fi Alliance.WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Normalized SKU: 0100232103UPC Code: 753759240806

Lowrance 055-14301-001 FishfindersHOOK2-9 9" Chartplotter/Fishfinder TripleShot Transom Mount Transducer w/Built-In U.S. Inland Charts *Remanufactured - 1-Year WarrantyThe world’s easiest fishfinder, HOOK2 9 TripleShot offers simple menus, easy access to key functions and Autotuning sonar. Powered by proven Lowrance® performance, HOOK2 9 features TripleShot 3-in-1 sonar with wide-angle, High CHIRP coverage, SideScan and DownScan Imaging™, plus a built-in, high-detail U.S. map. Just plug it in and fish. Yes, it's that easy.Features: 9-inch SolarMAX™ display - Get crisp and clear views of fish and fish-holding structure with the excellent clarity and daylight visibility of a high-resolution SolarMAX™ display. Automated sonar settings - You will spend more time fishing and less time dialing in your sonar with HOOK2 Autotuning sonar. Just plug it in and fish. It doesn't get any easier. Easiest-to-use menu operation and Dedicated Keypad - Make the adjustments you want with fewer key presses via a simplified menu layout and dedicated keypad. Exclusive Tripleshot™ 3-in-1 Sonar with High CHIRP, SideScan and DownScan Imaging™ - TripleShot three-in-one sonar makes it easier to stay on the fish, delivering the best traditional sonar views and lifelike images of fish-holding structure beneath and beside your boat. Built-in detailed mapping - Easily find depth changes, roadbeds or your favorite fishing spot on the built-in, high-detail U.S. map in HOOK2, featuring 1-foot contours or more than 3,000 lakes. Mapping options - You can easily upgrade the mapping on your HOOK2 with optional mapping cards from C-MAP, C-MAP Genesis, Navionics® and more. microSD card slot - -Save your waypoints, routes and trails to a microSD card or upgrade your mapping with an optional chart card. Easy front-dash or gimbal-bracket mounting installation - -Pick the best installation option for your boat from simple flush-mount and gimbal-bracket installation options.(Both Included) Specifications: Display: 9" (228.6mm) Resolution: 800 x 480 Backlighting: LED Power Output: TBD Operating Frequency: High CHIRP, Wide-angle 200kHz, 455/800 kHz, Media Port: One (1) microSD slot Operating Voltage: 10.4-17 VDC (min-max) Warranty: One year Depth Alarm: Yes Shallow Alarm: Yes Temperature Readings: Yes Transducer Type: TripleShot transducer Display Type: WVGA color TFT LCD Backlighting Levels: Adjustable Screen And Keypad Waterproof Standard/rating: IPx7 Product Width: 11.3" \ 287 mm Product Depth: 3.26" \ 83 mm Product Height: 6.39" \ 162 mm Power Supply (Supply Voltage): 12 vDC (10-17 vDC min-max) Routes storage: 100 Waypoint Storage: 3,000 GPS Antenna Type: Internal high-sensitivity Plot Trail storage: 100 GPS Alarms: Yes Custom Mapping: Optional Americas chart upgrades include C-MAP, Navionics® HotMaps® Premium and Fishing Hotspots® PRO. Global chart upgrade options include Navionics + and C-MAP MAX-N Background Mapping: Built-in high-detail US map with 1-foot contours on more than 3,000 lakes Normalized SKU: 05514301001UPC Code: 9420024169766

Download LiteratureGarmin 010-02341-01 FishfindersECHOMAP™ UHD 92sv with GT54UHD-TM TransducerJoin the Club. Find More Fish.The sunlight-readable 9” touchscreen chartplotter features a quick-release bail mount, and the transducer bundle adds Ultra High-Definition scanning sonar and CHIRP traditional sonar.Features: See below and around your boat in incredible detail with optional transducer  Navigate any waters with optional charts and maps  Share data with other devices on your network (7” and 9” models only)  Manage your marine experience from nearly anywhere  Control the most powerful trolling motor available  Create your own maps on the fly and tailor them to fit your needs Sonar SupportThis chartplotter supports a variety of Garmin transducers (sold separately), including the Panoptix LiveScope™ scanning sonar system, which lets you see all around your boat in real time. Optional Transducer BundleSelect the transducer bundle to add a GT54 transducer for Ultra High-Definition ClearVü and SideVü scanning sonars, which show you crystal-clear images below and around your boat. Plus, you get Garmin high wide CHIRP traditional sonar for remarkable target separation.Optional Charts and MapsExperience unparalleled coverage and detail with support for optional BlueChart® g3 Vision coastal charts featuring integrated Garmin and Navionics® content. Quickdraw ContoursCreate personalized fishing maps on-screen with 1’ contours. Keep the data to yourself, or share it with the Quickdraw Community on Garmin Connect™. Network CapableIf you have multiple compatible ECHOMAP UHD or ECHOMAP Ultra devices on your boat, you can share information — such as sonar, user data and charts — among them (7” and 9” models only). NMEA 2000® and NMEA 0183 NetworksConnect to autopilots, digital switching, weather, FUSION-Link™ audio system, media, VHF, AIS and more from one screen. ActiveCaptain® AppBuilt-in Wi-Fi® connectivity pairs with the free all-in-one mobile app for access to the OneChart™ feature, smart notifications1, software updates, Garmin Quickdraw™ Community data and more. Force™ Trolling Motor CompatibilityTake control of the most powerful and efficient trolling motor available2, route it to waypoints, follow tracks and more from the screen of your chartplotter. In The Box ECHOMAP UHD 92sv with worldwide basemap GT54UHD-TM transducer Power/data cable Tilt mount with quick release cradle Flush mount Protective cover Hardware Documentation 1 When paired with a compatible smartphone2 In compliance with ISO standard 13342Wi-Fi is a registered trademark of the Wi-Fi Alliance.WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Normalized SKU: 0100234101UPC Code: 753759241629Garmin 010-02341-01 Literature Download Owners Manual

Download Literature Watch VideoGarmin 010-02343-01 FishfindersECHOMAP™ UHD 94sv US Offshore g3 with GT54UHD-TM Transducer Find more fish using the ECHOMAP™ UHD 94sv combo with a bright, sunlight-readable 9” touchscreen with keyed assist. The optional GT54 transducer provides Ultra High-Definition ClearVü and SideVü scanning sonars, so you get crystal-clear images of what is around and below your boat, and Garmin high wide CHIRP traditional sonar delivers remarkable target separation. It comes preloaded with BlueChart® g3 coastal charts with the best of Garmin and Navionics® data. It features a quick-release bail mount, making it easy to remove and take with you. NMEA 2000® and NMEA 0183 network support provides you with engine data, sensor connection, autopilot integration and more. ECHOMAP™ UHD 94sv is even compatible with the Force™ trolling motor for full control of the motor from the screen plus the ability to route to waypoints, follow tracks and more. Features: Bright, sunlight-readable 9” touchscreen with keyed assist Includes transducer for Ultra High-Definition ClearVü and Ultra High-Definition SideVü scanning sonars and Garmin high wide CHIRP traditional sonar Preloaded BlueChart® g3 coastal charts with integrated Navionics® data Supports Panoptix™ all-seeing sonar, including Panoptix LiveScope™ sonar Sonar sharing capabilities with other ECHOMAP™ Plus, ECHOMAP UHD and ECHOMAP Ultra units NMEA 2000® and NMEA 0183 network support for autopilot and engine data Quick-release bail mount for fast and easy mobility Compatible with Force™ trolling motor for full control of the motor from the screen plus the ability to route to waypoints, follow tracks and more Included TransducerSelect the transducer bundle to add a GT54 transducer for Ultra High-Definition ClearVü and SideVü scanning sonars, which show you crystal-clear images below and around your boat. Plus, you get Garmin high wide CHIRP traditional sonar for remarkable target separation. Sonar SupportThis chartplotter supports a variety of Garmin transducers (sold separately), including the Panoptix LiveScope™ scanning sonar system, which lets you see all around your boat in real time.Preloaded ChartsExperience unparalleled coverage and detail with preloaded LakeVü g3 inland maps featuring integrated Navionics® data that covers more than 17,000 lakes with up to 1’ contours. Quickdraw ContoursCreate personalized fishing maps on-screen with 1’ contours. Keep the data to yourself, or share it with the Quickdraw Community on Garmin Connect™. NMEA 2000® & NMEA0183 NetworksConnect to autopilots, digital switching, weather, FUSION-Link™ audio system, media, VHF, AIS and more from one screen. ActiveCaptain® AppBuilt-in Wi-Fi® connectivity pairs with the free all-in-one mobile app for access to the OneChart™ feature, smart notifications1, software updates, Garmin Quickdraw™ Community data and more. Network CapableIf you have multiple compatible ECHOMAP UHD or ECHOMAP Ultra devices on your boat, you can share information — such as sonar, user data and charts — among them (7” and 9” models only). Force™ Trolling Motor CapabilityTake control of the most powerful and efficient trolling motor available2, route it to waypoints, follow tracks and more from the screen of your chartplotter.Connections Garmin Marine Network Ports: 1 NMEA 2000 Compatible: Yes Transducer Pin Numbers: 12 NMEA 0183 Input Ports: 1 NMEA 0183 Output Ports: 1 Video Input Ports: None Video Output Ports: None Wireless Connectivity: Yes In The Box ECHOMAP UHD 94sv with BlueChart g3 for U.S. GT54UHD-TM transducer Power/data cable Tilt mount with quick release cradle Flush mount Protective cover Hardware Documentation 1 When paired with a compatible smartphone2 In compliance with ISO standard 13342Wi-Fi is a registered trademark of the Wi-Fi Alliance.WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Normalized SKU: 0100234301UPC Code: 753759241667Garmin 010-02343-01 Literature Download Owners ManualGarmin 010-02343-01 Video

Download Literature Watch VideoGarmin 010-02339-01 FishfindersECHOMAP™ UHD 74sv US Offshore g3 with GT54UHD-TM TransducerFind more fish using the ECHOMAP™ UHD 74sv combo with a bright, sunlight-readable 7” touchscreen with keyed assist. The optional GT54 transducer provides Ultra High-Definition ClearVü and SideVü scanning sonars, so you get crystal-clear images of what is around and below your boat, and Garmin high wide CHIRP traditional sonar delivers remarkable target separation. It comes preloaded with BlueChart® g3 coastal charts with the best of Garmin and Navionics® data. It features a quick-release bail mount, making it easy to remove and take with you. NMEA 2000® and NMEA 0183 network support provides you with engine data, sensor connection, autopilot integration and more. ECHOMAP™ UHD 74sv is even compatible with the Force™ trolling motor for full control of the motor from the screen plus the ability to route to waypoints, follow tracks and more.Features: Bright, sunlight-readable 7” touchscreen with keyed assist Optional GT54 transducer for Ultra High-Definition ClearVü and Ultra High-Definition SideVü scanning sonars and Garmin high wide CHIRP traditional sonar Preloaded BlueChart® g3 coastal charts with integrated Navionics® data Supports Panoptix™ all-seeing sonar, including Panoptix LiveScope™ sonar Sonar sharing capabilities with other ECHOMAP™ Plus, ECHOMAP UHD and ECHOMAP Ultra units NMEA 2000® and NMEA 0183 network support for autopilot and engine data Quick-release bail mount for fast and easy mobility Compatible with Force™ trolling motor for full control of the motor from the screen plus the ability to route to waypoints, follow tracks and more Included TransducerThis chartplotter comes with a GT24 transducer for Ultra High-Definition ClearVü scanning sonar, which shows you a crystal-clear image below your boat. Plus, you get Garmin high wide CHIRP traditional sonar for remarkable target separation. Sonar SupportThis chartplotter supports a variety of Garmin transducers (sold separately), including the Panoptix LiveScope™ scanning sonar system, which lets you see all around your boat in real time.Preloaded ChartsExperience unparalleled coverage and detail with preloaded LakeVü g3 inland maps featuring integrated Navionics® data that covers more than 17,000 lakes with up to 1’ contours. Quickdraw ContoursCreate personalized fishing maps on-screen with 1’ contours. Keep the data to yourself, or share it with the Quickdraw Community on Garmin Connect™. NMEA 2000® & NMEA 0183 NetworksConnect to autopilots, digital switching, weather, FUSION-Link™ audio system, media, VHF, AIS and more from one screen. ActiveCaptain® AppBuilt-in Wi-Fi® connectivity pairs with the free all-in-one mobile app for access to the OneChart™ feature, smart notifications1, software updates, Garmin Quickdraw™ Community data and more. Network CapableIf you have multiple compatible ECHOMAP UHD or ECHOMAP Ultra devices on your boat, you can share information — such as sonar, user data and charts — among them (7” and 9” models only). Force™ Trolling Motor CapabilityTake control of the most powerful and efficient trolling motor available2, route it to waypoints, follow tracks and more from the screen of your chartplotter.Connections Garmin Marine Network Ports: 1 NMEA 2000 Compatible: Yes Transducer Pin Numbers: 12 NMEA 0183 Input Ports: 1 NMEA 0183 Output Ports: 1 Video Input Ports: None Video Output Ports: None Wireless Connectivity: Yes In The Box ECHOMAP UHD 74sv with BlueChart g3 for U.S. GT54UHD-TM transducer Power/data cable Tilt mount with quick release cradle Flush mount Protective cover Hardware Documentation 1 When paired with a compatible smartphone2 In compliance with ISO standard 13342Wi-Fi is a registered trademark of the Wi-Fi Alliance.WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Normalized SKU: 0100233901UPC Code: 753759241599Garmin 010-02339-01 Literature Download Owners ManualGarmin 010-02339-01 Video

Download Literature Watch VideoGarmin 010-02343-00 FishfindersECHOMAP™ UHD 94sv US Offshore g3 without TransducerFind more fish using the ECHOMAP™ UHD 94sv combo with a bright, sunlight-readable 9” touchscreen with keyed assist. The optional GT54 transducer provides Ultra High-Definition ClearVü and SideVü scanning sonars, so you get crystal-clear images of what is around and below your boat, and Garmin high wide CHIRP traditional sonar delivers remarkable target separation. It comes preloaded with BlueChart® g3 coastal charts with the best of Garmin and Navionics® data. It features a quick-release bail mount, making it easy to remove and take with you. NMEA 2000® and NMEA 0183 network support provides you with engine data, sensor connection, autopilot integration and more. ECHOMAP™ UHD 94sv is even compatible with the Force™ trolling motor for full control of the motor from the screen plus the ability to route to waypoints, follow tracks and more.Features: Bright, sunlight-readable 9” touchscreen with keyed assist Optional transducer for Ultra High-Definition ClearVü and Ultra High-Definition SideVü scanning sonars and Garmin high wide CHIRP traditional sonar Preloaded BlueChart® g3 coastal charts with integrated Navionics® data Supports Panoptix™ all-seeing sonar, including Panoptix LiveScope™ sonar Sonar sharing capabilities with other ECHOMAP™ Plus, ECHOMAP UHD and ECHOMAP Ultra units NMEA 2000® and NMEA 0183 network support for autopilot and engine data Quick-release bail mount for fast and easy mobility Compatible with Force™ trolling motor for full control of the motor from the screen plus the ability to route to waypoints, follow tracks and more waypoints, follow tracks and more Optional Transducer BundleSelect the transducer bundle to add a GT54 transducer for Ultra High-Definition ClearVü and SideVü scanning sonars, which show you crystal-clear images below and around your boat. Plus, you get Garmin high wide CHIRP traditional sonar for remarkable target separation.Sonar SupportThis chartplotter supports a variety of Garmin transducers (sold separately), including the Panoptix LiveScope™ scanning sonar system, which lets you see all around your boat in real time.Preloaded MappingExperience unparalleled coverage and detail with preloaded LakeVü g3 inland maps featuring integrated Navionics® data that covers more than 17,000 lakes with up to 1’ contours. Quickdraw ContoursCreate personalized fishing maps on-screen with 1’ contours. Keep the data to yourself, or share it with the Quickdraw Community on Garmin Connect™. NMEA 2000® & NMEA0183 NetworksConnect to autopilots, digital switching, weather, FUSION-Link™ audio system, media, VHF, AIS and more from one screen. ActiveCaptain® AppBuilt-in Wi-Fi® connectivity pairs with the free all-in-one mobile app for access to the OneChart™ feature, smart notifications1, software updates, Garmin Quickdraw™ Community data and more. Network CapableIf you have multiple compatible ECHOMAP UHD or ECHOMAP Ultra devices on your boat, you can share information — such as sonar, user data and charts — among them (7” and 9” models only). Force™ Trolling Motor CapabilityTake control of the most powerful and efficient trolling motor available2, route it to waypoints, follow tracks and more from the screen of your chartplotter.Connections Garmin Marine Network Ports: 1 NMEA 2000 Compatible: Yes Transducer Pin Numbers: 12 NMEA 0183 Input Ports: 1 NMEA 0183 Output Ports: 1 Video Input Ports: None Video Output Ports: None Wireless Connectivity: Yes In The Box ECHOMAP UHD 94sv with BlueChart g3 for U.S. 8-pin transducer to 12-pin sounder adapter cable Power/data cable Tilt mount with quick release cradle Flush mount Protective cover Hardware Documentation 1 When paired with a compatible smartphone2 In compliance with ISO standard 13342Wi-Fi is a registered trademark of the Wi-Fi Alliance.WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Normalized SKU: 0100234300UPC Code: 753759241650Garmin 010-02343-00 Literature Download Owners ManualGarmin 010-02343-00 Video

Download LiteratureGarmin 010-02338-00 FishfindersECHOMAP™ UHD 73sv US LakeVü g3 without TransducerFind more fish using the ECHOMAP™ UHD 73sv combo with a bright, sunlight-readable 7” touchscreen with keyed assist. The optional GT54 transducer provides Ultra High-Definition ClearVü and SideVü scanning sonars, so you get crystal-clear images of what is around and below your boat, and Garmin high wide CHIRP traditional sonar delivers remarkable target separation. Preloaded LakeVü g3 inland maps with integrated Navionics® data cover more than 17,000 lakes with up to 1’ contours. It features a quick-release bail mount, making it easy to remove and take with you.  NMEA 2000® and NMEA 0183 network support provides you with engine data, sensor connection, autopilot integration and more. ECHOMAP™ UHD 73sv is even compatible with the Force™ trolling motor for full control of the motor from the screen plus the ability to route to waypoints, follow tracks and more.Features: Bright, sunlight-readable 7” touchscreen with keyed assist Optional GT54 transducer for Ultra High-Definition ClearVü and Ultra High-Definition SideVü scanning sonars and Garmin high wide CHIRP traditional sonar Preloaded LakeVü g3 inland maps with integrated Navionics® data cover more than 17,000 lakes with up to 1’ contours Supports Panoptix™ all-seeing sonar, including Panoptix LiveScope™ sonar Sonar sharing capabilities with other ECHOMAP™ Plus, ECHOMAP UHD and ECHOMAP Ultra units NMEA 2000® and NMEA 0183 network support for autopilot and engine data Quick-release bail mount for fast and easy mobility Compatible with Force™ trolling motor for full control of the motor from the screen plus the ability to route to waypoints, follow tracks and more Optional Transducer BundleSelect the transducer bundle to add a GT54 transducer for Ultra High-Definition ClearVü and SideVü scanning sonars, which show you crystal-clear images below and around your boat. Plus, you get Garmin high wide CHIRP traditional sonar for remarkable target separation.Sonar SupportThis chartplotter supports a variety of Garmin transducers (sold separately), including the Panoptix LiveScope™ scanning sonar system, which lets you see all around your boat in real time.Preloaded MappingExperience unparalleled coverage and detail with preloaded LakeVü g3 inland maps featuring integrated Navionics® data that covers more than 17,000 lakes with up to 1’ contours. Quickdraw ContoursCreate personalized fishing maps on-screen with 1’ contours. Keep the data to yourself, or share it with the Quickdraw Community on Garmin Connect™. NMEA 2000® & NMEA 0183 NetworksConnect to autopilots, digital switching, weather, FUSION-Link™ audio system, media, VHF, AIS and more from one screen. ActiveCaptain® AppBuilt-in Wi-Fi® connectivity pairs with the free all-in-one mobile app for access to the OneChart™ feature, smart notifications1, software updates, Garmin Quickdraw™ Community data and more. Network CapableIf you have multiple compatible ECHOMAP UHD or ECHOMAP Ultra devices on your boat, you can share information — such as sonar, user data and charts — among them (7” and 9” models only). Force™ Trolling Motor CapabilityTake control of the most powerful and efficient trolling motor available2, route it to waypoints, follow tracks and more from the screen of your chartplotter.Connections Garmin Marine Network Ports: 1 NMEA 2000 Compatible: Yes Transducer Pin Numbers: 12 NMEA 0183 Input Ports: 1 NMEA 0183 Output Ports: 1 Video Input Ports: None Video Output Ports: None Wireless Connectivity: Yes In The Box ECHOMAP UHD 73sv with BlueChart g3 for U.S. Power/data cable Tilt mount with quick release cradle Flush mount Protective cover Hardware Documentation 1 When paired with a compatible smartphone2 In compliance with ISO standard 13342Wi-Fi is a registered trademark of the Wi-Fi Alliance.WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Normalized SKU: 0100233800UPC Code: 753759241568Garmin 010-02338-00 Literature Download Owners Manual

Download Literature Watch VideoGarmin 010-02339-00 FishfindersECHOMAP™ UHD 74sv US Offshore g3 without TransducerFind more fish using the ECHOMAP™ UHD 74sv combo with a bright, sunlight-readable 7” touchscreen with keyed assist. The optional GT54 transducer provides Ultra High-Definition ClearVü and SideVü scanning sonars, so you get crystal-clear images of what is around and below your boat, and Garmin high wide CHIRP traditional sonar delivers remarkable target separation. It comes preloaded with BlueChart® g3 coastal charts with the best of Garmin and Navionics® data. It features a quick-release bail mount, making it easy to remove and take with you. NMEA 2000® and NMEA 0183 network support provides you with engine data, sensor connection, autopilot integration and more. ECHOMAP™ UHD 74sv is even compatible with the Force™ trolling motor for full control of the motor from the screen plus the ability to route to waypoints, follow tracks and more.Features: Bright, sunlight-readable 7” touchscreen with keyed assist Optional GT54 transducer for Ultra High-Definition ClearVü and Ultra High-Definition SideVü scanning sonars and Garmin high wide CHIRP traditional sonar Preloaded BlueChart® g3 coastal charts with integrated Navionics® data Supports Panoptix™ all-seeing sonar, including Panoptix LiveScope™ sonar Sonar sharing capabilities with other ECHOMAP™ Plus, ECHOMAP UHD and ECHOMAP Ultra units NMEA 2000® and NMEA 0183 network support for autopilot and engine data Quick-release bail mount for fast and easy mobility Compatible with Force™ trolling motor for full control of the motor from the screen plus the ability to route to waypoints, follow tracks and more Optional Transducer BundleSelect the transducer bundle to add a GT54 transducer for Ultra High-Definition ClearVü and SideVü scanning sonars, which show you crystal-clear images below and around your boat. Plus, you get Garmin high wide CHIRP traditional sonar for remarkable target separation.Sonar SupportThis chartplotter supports a variety of Garmin transducers (sold separately), including the Panoptix LiveScope™ scanning sonar system, which lets you see all around your boat in real time.Preloaded MappingExperience unparalleled coverage and detail with preloaded LakeVü g3 inland maps featuring integrated Navionics® data that covers more than 17,000 lakes with up to 1’ contours. Quickdraw ContoursCreate personalized fishing maps on-screen with 1’ contours. Keep the data to yourself, or share it with the Quickdraw Community on Garmin Connect™. NMEA 2000® & NMEA0183 NetworksConnect to autopilots, digital switching, weather, FUSION-Link™ audio system, media, VHF, AIS and more from one screen. ActiveCaptain® AppBuilt-in Wi-Fi® connectivity pairs with the free all-in-one mobile app for access to the OneChart™ feature, smart notifications1, software updates, Garmin Quickdraw™ Community data and more. Network CapableIf you have multiple compatible ECHOMAP UHD or ECHOMAP Ultra devices on your boat, you can share information — such as sonar, user data and charts — among them (7” and 9” models only). Force™ Trolling Motor CapabilityTake control of the most powerful and efficient trolling motor available2, route it to waypoints, follow tracks and more from the screen of your chartplotter.Connections Garmin Marine Network Ports: 1 NMEA 2000 Compatible: Yes Transducer Pin Numbers: 12 NMEA 0183 Input Ports: 1 NMEA 0183 Output Ports: 1 Video Input Ports: None Video Output Ports: None Wireless Connectivity: Yes In The Box ECHOMAP UHD 74sv with BlueChart g3 for U.S. Power/data cable Tilt mount with quick release cradle Flush mount Protective cover Hardware Documentation 1 When paired with a compatible smartphone2 In compliance with ISO standard 13342Wi-Fi is a registered trademark of the Wi-Fi Alliance.WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Normalized SKU: 0100233900UPC Code: 753759241582Garmin 010-02339-00 Literature Download Owners ManualGarmin 010-02339-00 Video

Download LiteratureGarmin 010-02337-01 FishfindersECHOMAP™ UHD 72sv with GT54UHD-TM TransducerThe sunlight-readable 7” touchscreen chartplotter features a quick-release bail mount, and the transducer bundle adds Ultra High-Definition scanning sonar and CHIRP traditional sonar. Features: See below and around your boat in incredible detail with optional transducer Navigate any waters with optional charts and maps Share data with other devices on your network (7” and 9” models only) Manage your marine experience from nearly anywhere Control the most powerful trolling motor available Create your own maps on the fly and tailor them to fit your needs Sonar SupportThis chartplotter supports a variety of Garmin transducers (sold separately), including the Panoptix LiveScope™ scanning sonar system, which lets you see all around your boat in real time.Optional Transducer BundleSelect the transducer bundle to add a GT54 transducer for Ultra High-Definition ClearVü and SideVü scanning sonars, which show you crystal-clear images below and around your boat. Plus, you get Garmin high wide CHIRP traditional sonar for remarkable target separation.Optional Charts & MapsExperience unparalleled coverage and detail with support for optional BlueChart® g3 Vision coastal charts featuring integrated Garmin and Navionics® content.Quickdraw ContoursCreate personalized fishing maps on-screen with 1’ contours. Keep the data to yourself, or share it with the Quickdraw Community on Garmin Connect™.Network CapableIf you have multiple compatible ECHOMAP UHD or ECHOMAP Ultra devices on your boat, you can share information — such as sonar, user data and charts — among them (7” and 9” models only).NMEA 2000® & NMEA 0183 NetworksConnect to autopilots, digital switching, weather, FUSION-Link™ audio system, media, VHF, AIS and more from one screen.ActiveCaptain® APPBuilt-in Wi-Fi® connectivity pairs with the free all-in-one mobile app for access to the OneChart™ feature, smart notifications1, software updates, Garmin Quickdraw™ Community data and more.Force™ Trolling Motor CapabilityTake control of the most powerful and efficient trolling motor available2, route it to waypoints, follow tracks and more from the screen of your chartplotter.In The Box ECHOMAP UHD 72sv with worldwide basemap GT54UHD-TM transducer Power/data cable Tilt/swivel mount with quick release cradle Flush mount Protective cover Hardware Documentation 1 When paired with a compatible smartphone2 In compliance with ISO standard 13342Wi-Fi is a registered trademark of the Wi-Fi Alliance.WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Normalized SKU: 0100233701UPC Code: 753759241551Garmin 010-02337-01 Literature Download Owners Manual

Download LiteratureGarmin 010-02337-00 FishfindersECHOMAP™ UHD 72sv without TransducerThe sunlight-readable 7” touchscreen chartplotter features a quick-release bail mount, and the transducer bundle adds Ultra High-Definition scanning sonar and CHIRP traditional sonar. Features: See below and around your boat in incredible detail with optional transducer Navigate any waters with optional charts and maps Share data with other devices on your network (7” and 9” models only) Manage your marine experience from nearly anywhere Control the most powerful trolling motor available Create your own maps on the fly and tailor them to fit your needs Sonar SupportThis chartplotter supports a variety of Garmin transducers (sold separately), including the Panoptix LiveScope™ scanning sonar system, which lets you see all around your boat in real time.Optional Transducer BundleSelect the transducer bundle to add a GT54 transducer for Ultra High-Definition ClearVü and SideVü scanning sonars, which show you crystal-clear images below and around your boat. Plus, you get Garmin high wide CHIRP traditional sonar for remarkable target separation.Optional Charts & MapsExperience unparalleled coverage and detail with support for optional BlueChart® g3 Vision coastal charts featuring integrated Garmin and Navionics® content.Quickdraw ContoursCreate personalized fishing maps on-screen with 1’ contours. Keep the data to yourself, or share it with the Quickdraw Community on Garmin Connect™.Network CapableIf you have multiple compatible ECHOMAP UHD or ECHOMAP Ultra devices on your boat, you can share information — such as sonar, user data and charts — among them (7” and 9” models only).NMEA 2000® & NMEA 0183 NetworksConnect to autopilots, digital switching, weather, FUSION-Link™ audio system, media, VHF, AIS and more from one screen.ActiveCaptain® APPBuilt-in Wi-Fi® connectivity pairs with the free all-in-one mobile app for access to the OneChart™ feature, smart notifications1, software updates, Garmin Quickdraw™ Community data and more.Force™ Trolling Motor CapabilityTake control of the most powerful and efficient trolling motor available2, route it to waypoints, follow tracks and more from the screen of your chartplotter.In The Box ECHOMAP UHD 72sv with worldwide basemap 8-pin transducer to 12-pin sounder adapter cable Power/data cable Tilt/swivel mount with quick release cradle Flush mount Protective cover Hardware Documentation 1 When paired with a compatible smartphone2 In compliance with ISO standard 13342Wi-Fi is a registered trademark of the Wi-Fi Alliance.WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Normalized SKU: 0100233700UPC Code: 753759241544Garmin 010-02337-00 Literature Download Owners Manual

Download LiteratureGarmin 010-02335-01 FishfindersECHOMAP™ UHD 74cv US Offshore g3 with GT24UHD-TM TransducerFind more fish using the ECHOMAP™ UHD 74cv combo with a bright, sunlight-readable 7” touchscreen with keyed assist. The included GT24 transducer provides Ultra High-Definition ClearVü scanning sonar, so you get a crystal-clear image of what is below your boat, and Garmin high wide CHIRP traditional sonar delivers remarkable target separation. This combo comes preloaded with BlueChart® g3 coastal charts with the best of Garmin and Navionics® data. It features a quick-release bail mount, making it easy to remove and take with you. NMEA 2000® and NMEA 0183 network support provides you with engine data, sensor connection, autopilot integration and more. ECHOMAP™ UHD 74cv is even compatible with the Force™ trolling motor for full control of the motor from the screen plus the ability to route to waypoints, follow tracks and more.Features: Bright, sunlight-readable 7” touchscreen with keyed assist Includes GT24 transducer for Ultra High-Definition ClearVü scanning sonar and Garmin high wide CHIRP traditional sonar Preloaded BlueChart® g3 coastal charts with integrated Navionics® data Supports Panoptix™ all-seeing sonar, including Panoptix LiveScope™ sonar Sonar sharing capabilities with other ECHOMAP™ Plus, ECHOMAP UHD and ECHOMAP Ultra units NMEA 2000® and NMEA 0183 network support for autopilot and engine data Quick-release bail mount for fast and easy mobility Compatible with Force™ trolling motor for full control of the motor from the screen plus the ability to route to waypoints, follow tracks and more Included TransducerThis chartplotter comes with a GT24 transducer for Ultra High-Definition ClearVü scanning sonar, which shows you a crystal-clear image below your boat. Plus, you get Garmin high wide CHIRP traditional sonar for remarkable target separation. Sonar SupportThis chartplotter supports a variety of Garmin transducers (sold separately), including the Panoptix LiveScope™ scanning sonar system, which lets you see all around your boat in real time.Preloaded ChartsExperience unparalleled coverage and detail with preloaded LakeVü g3 inland maps featuring integrated Navionics® data that covers more than 17,000 lakes with up to 1’ contours. Quickdraw ContoursCreate personalized fishing maps on-screen with 1’ contours. Keep the data to yourself, or share it with the Quickdraw Community on Garmin Connect™. NMEA 2000® & NMEA0183 NetworksConnect to autopilots, digital switching, weather, FUSION-Link™ audio system, media, VHF, AIS and more from one screen. ActiveCaptain® AppBuilt-in Wi-Fi® connectivity pairs with the free all-in-one mobile app for access to the OneChart™ feature, smart notifications1, software updates, Garmin Quickdraw™ Community data and more. Network CapableIf you have multiple compatible ECHOMAP UHD or ECHOMAP Ultra devices on your boat, you can share information — such as sonar, user data and charts — among them (7” and 9” models only). Force™ Trolling Motor CapabilityTake control of the most powerful and efficient trolling motor available2, route it to waypoints, follow tracks and more from the screen of your chartplotter.Connections Garmin Marine Network Ports: 1 NMEA 2000 Compatible: Yes Transducer Pin Numbers: 12 NMEA 0183 Input Ports: 1 NMEA 0183 Output Ports: 1 Video Input Ports: None Video Output Ports: None Wireless Connectivity: Yes In The Box ECHOMAP UHD 74cv with BlueChart g3 for U.S. GT24UHD-TM transducer Power/data cable Tilt mount with quick release cradle Flush mount Protective cover Hardware Documentation 1 When paired with a compatible smartphone2 In compliance with ISO standard 13342Wi-Fi is a registered trademark of the Wi-Fi Alliance.WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Normalized SKU: 0100233501UPC Code: 753759241506Garmin 010-02335-01 Literature Download Owners Manual
