Newmar DCE Components"Displays volts, amps, energy used and remaining for 12 or 24 volt systems up to 500 amps and up to 3,000 amp-hour capacity. Makes DC energy management a breeze. Monitor voltage on up to three separate banks. House bank (or battery bank of choice) may be also be programmed for the following functions: 1) Monitor charge/discharge amperage. 2) Total energy monitor can be set for amp-hours or percent-of-charge. 3) High/low voltage alarm, plus alarm set-point for low amp-hours remaining. 500 amp shunt included. NMEA 0183 compatible output for data logging. 2 1/2" square face "Normalized SKU: DCE

Newmar ERC-12-15 Components"The Emergency Relay/Charger is a device for assuring immediate back-up power to communications equipment in the event AC power is temporarily lost to the power supply or the supply fails. In addition it will allow the power supply to act as a ?trickle? battery charger without any additional modification. When loss of DC voltage is sensed by the ERC, it employs a fast-acting S.P.D.T. relay to automatically switch the equipment?s DC input over to a standby battery to allow continued operation. When the power supply is returned to service, the ERC disengages the battery and puts the supply back on line to provide DC voltage. While the power supply is operating normally, a small portion of the output current is directed to the battery to trickle-charge and maintain it at full voltage.( Note: Battery float voltage will be maintained at .7 volts lower than power supply voltage) Note: If the power supply is down for an extended period, the back-up battery may become significantly discharged while powering the radio. When the supply returns to service, the trickle charge rate of the ERC may be insufficient to restore the battery to full charge in a timely manner. In the event this occurs, a supplemental charger may be necessary to bring the battery to full charge.   ERC12-15 ERC24-15 ERC12-35 Input range 10.0 - 14.5 VDC 20. - 29.0 VDC 10.0 - 14.5VDC Relay ratings 10 Amps Continuous15 Amps intermittant 10 Amps Continuous15 Amps intermittant 30 Amps Continuous35 Amps intermittant Float Trickle Typical 0.1 amps 0.2 amps .01 amps Dimensions 5 1/8" x 2 7/8" x 2 3/8' 5 1/8" x 2 7/8" x 2 3/8' 5 1/8" x 2 7/8" x 3 5/8" "Normalized SKU: ERC1215

Newmar CCX-T Components" Model Cable Diameter Range Max Connector Diameter Typical Connector CCX-R .47"-.59" 1.57" Large Radar Plug CCX-S .35"-.55" .83" Small Radar Plugs CCX-T .18"-.35" .83" PL-259, BNC, Wind Instrument Plugs "Normalized SKU: CCXT

Newmar BX-3 Components"BX Series Provides for secure, protected below-deck wiring connections, IP rating 54 Rugged cast aluminum box with white enamel finish Easy wiring access through multiple grommeted cable entries Supplied with high quality connector strips Secure wires w/compression fittings ? no terminals required. Specifications Model BX-2 BX-3 Number of Connector Strips 1 2 Positions per Strip 12 11 Max Wire Gauge 16 14 Max amps (per Position) 6 10 Cable Entries 8 2 Max Cable Diameter .37" .59" Box Sizes - Inches 4.4" x 2.4" x 1.2" 4.7" x 3.7" x 1.3" Box Sizes - Centimeters 11.2 x 6.1 x 3.1 11.9 x 9.4 x 3.3 "Normalized SKU: BX3

Newmar BX-2 Components"BX Series Provides for secure, protected below-deck wiring connections, IP rating 54 Rugged cast aluminum box with white enamel finish Easy wiring access through multiple grommeted cable entries Supplied with high quality connector strips Secure wires w/compression fittings ? no terminals required. Specifications Model BX-2 BX-3 Number of Connector Strips 1 2 Positions per Strip 12 11 Max Wire Gauge 16 14 Max amps (per Position) 6 10 Cable Entries 8 2 Max Cable Diameter .37" .59" Box Sizes - Inches 4.4" x 2.4" x 1.2" 4.7" x 3.7" x 1.3" Box Sizes - Centimeters 11.2 x 6.1 x 3.1 11.9 x 9.4 x 3.3 "Normalized SKU: BX2

Newmar CCX-R Components" Model Cable Diameter Range Max Connector Diameter Typical Connector CCX-R .47"-.59" 1.57" Large Radar Plug CCX-S .35"-.55" .83" Small Radar Plugs CCX-T .18"-.35" .83" PL-259, BNC, Wind Instrument Plugs "Normalized SKU: CCXR

Newmar ACE ComponentsFor 115/230 volt systems. Reads: 90-300 VAC, 0-150 amps, frequency from 40-70 Hz and power from 0-45 kW. Features alarm circuits for high/low voltage and high/low frequency. Can be programmed to provide automatic generator shutdown (see Remote Alarm Option below) in the event that voltage or frequency exceed predetermined range. Current and voltage transformers are included. 12 or 24 volt source required to power meter.  2 1/2 " faceNormalized SKU: ACE

Newmar 115-24-35CD Components"Heavy Duty Series Designed for powering 12 and 24 VDC communication/navigation equipment aboard commercial vessels where reliability is the primary consideration. Input voltage 115 or 230 VAC selected by slide switch on the front panel. Excellent Regulation and Ripple Spec: Output voltage maintained within 1% under all line and load conditions within rating; Ripple is less than 40 mV P-P. (12 volt) or 70 mV P-P (24-volt) Polyurethane conformal coated PC board and corrosion resistant heavy duty aluminum case with integral shock mounts assures survival in hostile environments Heat generated by semi-conductors is extracted and dissipated by large heat sink fins that maximize air contact for cool operation and long life of components. Supply and Load Circuit Protection: overvoltage, current limit; (set @ 105% of intermittent rating), thermal overload and input/output fusing. Thermally activated cooling fan on ""CD"" units. Specifications 12 Volt Output 115-12-8 Input 115/230 VAC Output 8 amp intermittent 5 amps continuous Dimensions 6.0" h x 4.6" w x 8.5" d wieght 10lbs 115-12-20A Input 115/230 VAC Output 20 amp intermittent 8 amps continuous Dimensions 5.7" h x 4.8" w x 16.3" d  weight 20lbs 115-12-35CD Input 115/230 VAC Output 35 amp intermittent 35 amps continuous Dimensions 6.5" h x 9.5" w x 14.0" d  Weight 32lbs 24-Volt Output 115-24-10 Input 115/230 VAC Output 10 amp intermittent 4 amps continuous Dimensions 5.7" h x 4.8" w x 16.3" d  weight 20lbs 115-24-18CD Input 115/230 VAC Output 18 amp intermittent 18 amps continuous Dimensions 6.5" h x 9.5" w x 14.0" d  Weight 32lb 115-24-35CD Input 115/230 VAC Output 35 amp intermittent 35 amps continuous Dimensions 6.5" h x 13.0" w x 18.75" d  Weight 60lbs Output Voltage 12 V Models: 13.6 VDC (Internally adjustable 12.6-14.5 VDC) Ripple: 40mV P-P ( @ 110-125 / 220-250 VAC input) 24 V Models: 24.5 VDC (Internally adjustable 21-27.5 VDC) Ripple: 70mV P-P ( @ 110-125 / 220-250 VAC input) Regulation All Models: 1% Line and Load (@ 110-125 / 220-250 VAC input) Input Range 105-125/210-250 VAC (selectable), 50-60 Hz Derate to 50% output below 110 and 220 VAC Operating Temperature 0-50°C, Derate Linearly From 100% @ 40°C To 50% @ 50°C Thermal shutdown @ 85°C Case temperature Duty Cycle Intermittent: 20 minutes max on time, 20% duty Continuous: 24 Hours/Day 100% Duty"Normalized SKU: 1152435CD

Newmar 115-12-35CD Components Heavy Duty Series Designed for powering 12 and 24 VDC communication/navigation equipment aboard commercial vessels where reliability is the primary consideration. Input voltage 115 or 230 VAC selected by slide switch on the front panel. Excellent Regulation and Ripple Spec: Output voltage maintained within 1% under all line and load conditions within rating; Ripple is less than 40 mV P-P. (12 volt) or 70 mV P-P (24-volt) Polyurethane conformal coated PC board and corrosion resistant heavy duty aluminum case with integral shock mounts assures survival in hostile environments Heat generated by semi-conductors is extracted and dissipated by large heat sink fins that maximize air contact for cool operation and long life of components. Supply and Load Circuit Protection: overvoltage, current limit; (set @ 105% of intermittent rating), thermal overload and input/output fusing. Thermally activated cooling fan on ""CD"" units. Specifications 12 Volt Output 115-12-8 Input 115/230 VAC Output 8 amp intermittent 5 amps continuous Dimensions 6.0" h x 4.6" w x 8.5" d wieght 10lbs115-12-20A Input 115/230 VAC Output 20 amp intermittent 8 amps continuous Dimensions 5.7" h x 4.8" w x 16.3" d  weight 20lbs 115-12-35CD Input 115/230 VAC Output 35 amp intermittent 35 amps continuous Dimensions 6.5" h x 9.5" w x 14.0" d  Weight 32lbs 24-Volt Output 115-24-10 Input 115/230 VAC Output 10 amp intermittent 4 amps continuous Dimensions 5.7" h x 4.8" w x 16.3" d  weight 20lbs115-24-18CD Input 115/230 VAC Output 18 amp intermittent 18 amps continuous Dimensions 6.5" h x 9.5" w x 14.0" d  Weight 32lb115-24-35CD Input 115/230 VAC Output 35 amp intermittent 35 amps continuous Dimensions 6.5" h x 13.0" w x 18.75" d  Weight 60lbs Output Voltage 12 V Models:13.6 VDC (Internally adjustable 12.6-14.5 VDC) Ripple: 40mV P-P ( @ 110-125 / 220-250 VAC input) 24 V Models:24.5 VDC (Internally adjustable 21-27.5 VDC)Ripple: 70mV P-P ( @ 110-125 / 220-250 VAC input) Regulation All Models: 1% Line and Load (@ 110-125 / 220-250 VAC input) Input Range 105-125/210-250 VAC (selectable), 50-60 Hz Derate to 50% output below 110 and 220 VAC Operating Temperature 0-50°C, Derate Linearly From 100% @ 40°C To 50% @ 50°C Thermal shutdown @ 85°C Case temperature Duty Cycle Intermittent: 20 minutes max on time, 20% dutyContinuous: 24 Hours/Day 100% Duty Normalized SKU: 1151235CDUPC Code: 400-0154-0

Newmar 115-12-8 Components"Heavy Duty Series Designed for powering 12 and 24 VDC communication/navigation equipment aboard commercial vessels where reliability is the primary consideration. Input voltage 115 or 230 VAC selected by slide switch on the front panel. Excellent Regulation and Ripple Spec: Output voltage maintained within 1% under all line and load conditions within rating; Ripple is less than 40 mV P-P. (12 volt) or 70 mV P-P (24-volt) Polyurethane conformal coated PC board and corrosion resistant heavy duty aluminum case with integral shock mounts assures survival in hostile environments Heat generated by semi-conductors is extracted and dissipated by large heat sink fins that maximize air contact for cool operation and long life of components. Supply and Load Circuit Protection: overvoltage, current limit; (set @ 105% of intermittent rating), thermal overload and input/output fusing. Thermally activated cooling fan on ""CD"" units. Specifications 12 Volt Output 115-12-8 Input 115/230 VAC Output 8 amp intermittent 5 amps continuous Dimensions 6.0" h x 4.6" w x 8.5" d wieght 10lbs 115-12-20A Input 115/230 VAC Output 20 amp intermittent 8 amps continuous Dimensions 5.7" h x 4.8" w x 16.3" d  weight 20lbs 115-12-35CD Input 115/230 VAC Output 35 amp intermittent 35 amps continuous Dimensions 6.5" h x 9.5" w x 14.0" d  Weight 32lbs 24-Volt Output 115-24-10 Input 115/230 VAC Output 10 amp intermittent 4 amps continuous Dimensions 5.7" h x 4.8" w x 16.3" d  weight 20lbs 115-24-18CD Input 115/230 VAC Output 18 amp intermittent 18 amps continuous Dimensions 6.5" h x 9.5" w x 14.0" d  Weight 32lb 115-24-35CD Input 115/230 VAC Output 35 amp intermittent 35 amps continuous Dimensions 6.5" h x 13.0" w x 18.75" d  Weight 60lbs Output Voltage 12 V Models: 13.6 VDC (Internally adjustable 12.6-14.5 VDC) Ripple: 40mV P-P ( @ 110-125 / 220-250 VAC input) 24 V Models: 24.5 VDC (Internally adjustable 21-27.5 VDC) Ripple: 70mV P-P ( @ 110-125 / 220-250 VAC input) Regulation All Models: 1% Line and Load (@ 110-125 / 220-250 VAC input) Input Range 105-125/210-250 VAC (selectable), 50-60 Hz Derate to 50% output below 110 and 220 VAC Operating Temperature 0-50°C, Derate Linearly From 100% @ 40°C To 50% @ 50°C Thermal shutdown @ 85°C Case temperature Duty Cycle Intermittent: 20 minutes max on time, 20% duty Continuous: 24 Hours/Day 100% Duty"Normalized SKU: 115128

Newmar 115-24-18CD Components"Heavy Duty Series Designed for powering 12 and 24 VDC communication/navigation equipment aboard commercial vessels where reliability is the primary consideration. Input voltage 115 or 230 VAC selected by slide switch on the front panel. Excellent Regulation and Ripple Spec: Output voltage maintained within 1% under all line and load conditions within rating; Ripple is less than 40 mV P-P. (12 volt) or 70 mV P-P (24-volt) Polyurethane conformal coated PC board and corrosion resistant heavy duty aluminum case with integral shock mounts assures survival in hostile environments Heat generated by semi-conductors is extracted and dissipated by large heat sink fins that maximize air contact for cool operation and long life of components. Supply and Load Circuit Protection: overvoltage, current limit; (set @ 105% of intermittent rating), thermal overload and input/output fusing. Thermally activated cooling fan on ""CD"" units. Specifications 12 Volt Output 115-12-8 Input 115/230 VAC Output 8 amp intermittent 5 amps continuous Dimensions 6.0" h x 4.6" w x 8.5" d wieght 10lbs 115-12-20A Input 115/230 VAC Output 20 amp intermittent 8 amps continuous Dimensions 5.7" h x 4.8" w x 16.3" d  weight 20lbs 115-12-35CD Input 115/230 VAC Output 35 amp intermittent 35 amps continuous Dimensions 6.5" h x 9.5" w x 14.0" d  Weight 32lbs 24-Volt Output 115-24-10 Input 115/230 VAC Output 10 amp intermittent 4 amps continuous Dimensions 5.7" h x 4.8" w x 16.3" d  weight 20lbs 115-24-18CD Input 115/230 VAC Output 18 amp intermittent 18 amps continuous Dimensions 6.5" h x 9.5" w x 14.0" d  Weight 32lb 115-24-35CD Input 115/230 VAC Output 35 amp intermittent 35 amps continuous Dimensions 6.5" h x 13.0" w x 18.75" d  Weight 60lbs Output Voltage 12 V Models: 13.6 VDC (Internally adjustable 12.6-14.5 VDC) Ripple: 40mV P-P ( @ 110-125 / 220-250 VAC input) 24 V Models: 24.5 VDC (Internally adjustable 21-27.5 VDC) Ripple: 70mV P-P ( @ 110-125 / 220-250 VAC input) Regulation All Models: 1% Line and Load (@ 110-125 / 220-250 VAC input) Input Range 105-125/210-250 VAC (selectable), 50-60 Hz Derate to 50% output below 110 and 220 VAC Operating Temperature 0-50°C, Derate Linearly From 100% @ 40°C To 50% @ 50°C Thermal shutdown @ 85°C Case temperature Duty Cycle Intermittent: 20 minutes max on time, 20% duty Continuous: 24 Hours/Day 100% Duty"Normalized SKU: 1152418CD

Newmar 115-24-10 Components"Heavy Duty Series Designed for powering 12 and 24 VDC communication/navigation equipment aboard commercial vessels where reliability is the primary consideration. Input voltage 115 or 230 VAC selected by slide switch on the front panel. Excellent Regulation and Ripple Spec: Output voltage maintained within 1% under all line and load conditions within rating; Ripple is less than 40 mV P-P. (12 volt) or 70 mV P-P (24-volt) Polyurethane conformal coated PC board and corrosion resistant heavy duty aluminum case with integral shock mounts assures survival in hostile environments Heat generated by semi-conductors is extracted and dissipated by large heat sink fins that maximize air contact for cool operation and long life of components. Supply and Load Circuit Protection: overvoltage, current limit; (set @ 105% of intermittent rating), thermal overload and input/output fusing. Thermally activated cooling fan on ""CD"" units. Specifications 12 Volt Output 115-12-8 Input 115/230 VAC Output 8 amp intermittent 5 amps continuous Dimensions 6.0" h x 4.6" w x 8.5" d wieght 10lbs 115-12-20A Input 115/230 VAC Output 20 amp intermittent 8 amps continuous Dimensions 5.7" h x 4.8" w x 16.3" d  weight 20lbs 115-12-35CD Input 115/230 VAC Output 35 amp intermittent 35 amps continuous Dimensions 6.5" h x 9.5" w x 14.0" d  Weight 32lbs 24-Volt Output 115-24-10 Input 115/230 VAC Output 10 amp intermittent 4 amps continuous Dimensions 5.7" h x 4.8" w x 16.3" d  weight 20lbs 115-24-18CD Input 115/230 VAC Output 18 amp intermittent 18 amps continuous Dimensions 6.5" h x 9.5" w x 14.0" d  Weight 32lb 115-24-35CD Input 115/230 VAC Output 35 amp intermittent 35 amps continuous Dimensions 6.5" h x 13.0" w x 18.75" d  Weight 60lbs Output Voltage 12 V Models: 13.6 VDC (Internally adjustable 12.6-14.5 VDC) Ripple: 40mV P-P ( @ 110-125 / 220-250 VAC input) 24 V Models: 24.5 VDC (Internally adjustable 21-27.5 VDC) Ripple: 70mV P-P ( @ 110-125 / 220-250 VAC input) Regulation All Models: 1% Line and Load (@ 110-125 / 220-250 VAC input) Input Range 105-125/210-250 VAC (selectable), 50-60 Hz Derate to 50% output below 110 and 220 VAC Operating Temperature 0-50°C, Derate Linearly From 100% @ 40°C To 50% @ 50°C Thermal shutdown @ 85°C Case temperature Duty Cycle Intermittent: 20 minutes max on time, 20% duty Continuous: 24 Hours/Day 100% Duty"Normalized SKU: 1152410UPC Code: 400-2115-0

Newmar 10ASB Components"All circuit breakers offered by NEWMAR are UL recognized and CSA listed for AC and DC systems and meet USCG requirements as a qualified circuit protection device. Single and Double Pole Fit all NEWMAR electrical panels, as well as most other brands Feature magnetic-hydraulic ""trip-free"" mechanism 5-30 amp rated to 65 VDC or 277 VAC; 40, 50 amp rated to 32 VDC or 120 VAC (See rating note below). Mounting scrws not provide order separatly #10 screw terminals on rear for wiring Options Red, white or black toggle handles Single pole values: 5, 10, 15, 20, 25, 30, 40 or 50 amp. Double pole values: 15, 20, 30 or 50 amp Important Circuit Breaker Rating Note: Standard series breakers shown on this page which are rated higher than 30 amps are acceptable for use in 230 VAC Line-to-Line systems (where each leg is 115 VAC - to - neutral), but are not rated for 230 VAC line-to-neutral systems."Normalized SKU: 10ASB

Newmar 115-12-20A Components"Heavy Duty Series Designed for powering 12 and 24 VDC communication/navigation equipment aboard commercial vessels where reliability is the primary consideration. Input voltage 115 or 230 VAC selected by slide switch on the front panel. Excellent Regulation and Ripple Spec: Output voltage maintained within 1% under all line and load conditions within rating; Ripple is less than 40 mV P-P. (12 volt) or 70 mV P-P (24-volt) Polyurethane conformal coated PC board and corrosion resistant heavy duty aluminum case with integral shock mounts assures survival in hostile environments Heat generated by semi-conductors is extracted and dissipated by large heat sink fins that maximize air contact for cool operation and long life of components. Supply and Load Circuit Protection: overvoltage, current limit; (set @ 105% of intermittent rating), thermal overload and input/output fusing. Thermally activated cooling fan on ""CD"" units. Specifications 12 Volt Output 115-12-8 Input 115/230 VAC Output 8 amp intermittent 5 amps continuous Dimensions 6.0" h x 4.6" w x 8.5" d wieght 10lbs 115-12-20A Input 115/230 VAC Output 20 amp intermittent 8 amps continuous Dimensions 5.7" h x 4.8" w x 16.3" d  weight 20lbs 115-12-35CD Input 115/230 VAC Output 35 amp intermittent 35 amps continuous Dimensions 6.5" h x 9.5" w x 14.0" d  Weight 32lbs 24-Volt Output 115-24-10 Input 115/230 VAC Output 10 amp intermittent 4 amps continuous Dimensions 5.7" h x 4.8" w x 16.3" d  weight 20lbs 115-24-18CD Input 115/230 VAC Output 18 amp intermittent 18 amps continuous Dimensions 6.5" h x 9.5" w x 14.0" d  Weight 32lb 115-24-35CD Input 115/230 VAC Output 35 amp intermittent 35 amps continuous Dimensions 6.5" h x 13.0" w x 18.75" d  Weight 60lbs Output Voltage 12 V Models: 13.6 VDC (Internally adjustable 12.6-14.5 VDC) Ripple: 40mV P-P ( @ 110-125 / 220-250 VAC input) 24 V Models: 24.5 VDC (Internally adjustable 21-27.5 VDC) Ripple: 70mV P-P ( @ 110-125 / 220-250 VAC input) Regulation All Models: 1% Line and Load (@ 110-125 / 220-250 VAC input) Input Range 105-125/210-250 VAC (selectable), 50-60 Hz Derate to 50% output below 110 and 220 VAC Operating Temperature 0-50°C, Derate Linearly From 100% @ 40°C To 50% @ 50°C Thermal shutdown @ 85°C Case temperature Duty Cycle Intermittent: 20 minutes max on time, 20% duty Continuous: 24 Hours/Day 100% Duty"Normalized SKU: 1151220AUPC Code: 400-0141-0

Newmar APS-70 Components"Automatic Power Selectors The Automatic Power Selector (APS) is a solid state device which enables installation of a seamless, redundant power system for critical electronic loads. It selects the higher voltage of two independent DC power sources and routes power to the load. Should one source falter or fail, the other will automatically supply the load with no transfer delay, operation continues uninterrupted. Easy installation, two independent power sources are wired to the APS and routed in a single output to the vital load. Alarm sense wires can be easily attached to input studs providing loss of power source signal. Rugged, rust-proof anodized aluminum case.   Model Max Loads Voltage Rating Stud Terminal Size Dimensions (Inches) Weight (Lbs.) APS-70 70 Amps 6 - 50 VDC, neg. ground 6mm 3.25 x 4.5 x 3.1 2 "Normalized SKU: APS70
