Blue Sea System 1829 ComponentsBlue Sea AC Current Transformer - 300A AC/50mA ACModel: 1829-BSSSpecifications Inside Diameter 1.25in (31.75 mm) Outside Diameter 2.68in (68.07 mm) Weight 4.00lb (1.81 kg) Normalized SKU: 1829UPC Code: 632085018290

EGIS 7022 ComponentsEGIS 250A 12/24v Contactor with Auxiliary ContactsModel: 7022 Sealed Enclosure: Hermetically sealed against dust and moisture penetration. High temp rated for all installation locations. 18-8 Stainless Self-Locking Hardware: Resists corrosion and ensure long term connection reliability with premium hardware. Easy Mounting: Reinforced mounting holes provide secure installation and easy attachment for the installer. Remote Status Support: Optional auxiliary contacts that support remote status indication. Ignition Protected safe for installation in closed compartments with potential explosive gasesHigh Electrical Switching Endurance delivers 6,000 cycles at 250A / 450V, 100,000 cycles at 250A / 14VHigh Interrupt Current Capability safely able to open in a locked starter situation (up to 1,500 A @ 14 Vdc)Bullet-proof Construction: Sealed device, high temp materials for engine compartment applications, and stainless self-locking hardware.4 Year Industry Leading WarrantySpecifications CONTINUOUS CURRENT (AMPS) 250/500 OPERATION CONTROL VOLTAGE 9-36 Vdc INGRESS PROTECTION IP67 / IP69K IGNITION PROTECTION ISO-8846 / UL 1500 MIN OPERATE TEMP (DEG C) -40 MAX OPERATE TEMP (DEG C) 85 Normalized SKU: 7022UPC Code: 850035199770

Sea-Dog 426162-1 ComponentsMachined Brass/Molded Bakelite & NeopreneThe Polarized Molded Electrical Connector is constructed of a molded Bakelite and neoprene body with machined brass polarized pins. Pins are sized differently, ensuring only one way to connect the plug, avoiding reverse polarity issues. 3-5A. 12/24 VDC. 14 Ga. wire Max. Wire attaches with brass set screws.This product replaces:426162-1, 426162, 3-426162Normalized SKU: 4261621UPC Code: 035514426237

Download LiteratureEgis 7026 ComponentsContactor 100A, 24V with Aux ContactsThis 100A Egis contactor is perfect for reducing installation costs and weight by eliminating large cable runs to manual switches through robust remote switching of high-ampere engines and auxiliary loads. Also, this contactor has a side mount.Applications: Ensure flawless operation for the life of the installation with a hermetically sealed contactor sealed against dust & moisture Intrusion. High Contact Voltage Rating easily supports 12 or 24 Vdc control voltage applications while also supporting higher switching voltage applications up to 48 V and well beyond. Get positive confirmation of the relay on/off state with optional auxiliary contacts that support remote status indication. Features: Ignition is protected and safe for installation in closed compartments with potential explosive gases High Electrical Switching Endurance delivers 6,000 cycles at 100A / 350V,  100,000 cycles at 100A / 14V High Interrupt Current Capability - safely able to open in a locked starter situation (up to 1,250 A @ 14 Vdc) Bullet-proof Construction - sealed device, high-temperature materials for engine compartment applications, and stainless self-locking hardware. 4 Year Industry Leading Warranty   Specifications: Continuous Current (Amps): 100 Operation Control Voltage: 16-28 VDC Ingress Protection: IP67/IP69K Ignition Protection: ISO-8846 / UL 1500 Minimum Operate Temp. (Deg C): -40 C Max Operate Temp. (Deg C): 85 Focal Features:Sealed EnclosureHermetically sealed against dust and moisture penetration. The high temperature rating for all installation locations.18-8 Stainless Steel Self-Locking HardwareIt resists corrosion and ensures long-term connection reliability with premium hardware.Easy MountingReinforced mounting holes provide secure installation and easy attachment for the installer.Remote Status SupportOptional auxiliary contacts that support remote status indication.WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Normalized SKU: 7026UPC Code: 850035199589Egis 7026 Literature Download Quick Reference Guide Owners Manual

Download LiteratureEgis 7024 ComponentsContactor 100A, 12V with Aux ContactsThis 100A Egis contactor is perfect for reducing installation costs and weight by eliminating large cable runs to manual switches through robust remote switching of high-ampere engines and auxiliary loads. Also, this contactor has a side mount.Applications: Ensure flawless operation for the life of the installation with a hermetically sealed contactor sealed against dust & moisture Intrusion. High Contact Voltage Rating easily supports 12 or 24 Vdc control voltage applications while also supporting higher switching voltage applications up to 48 V and well beyond. Get positive confirmation of the relay on/off state with optional auxiliary contacts that support remote status indication. Features: Ignition is protected and safe for installation in closed compartments with potential explosive gases High Electrical Switching Endurance delivers 6,000 cycles at 100A / 350V and 100,000 cycles at 100A / 14V High Interrupt Current Capability - safely able to open in a locked starter situation (up to 1,250 A @ 14 Vdc) Bullet-proof Construction - sealed device, high-temperature materials for engine compartment applications, and stainless self-locking hardware. 4 Year Industry Leading Warranty   Specifications: Continuous Current (Amps): 100 Operation Control Voltage: 8-16 VDC Ingress Protection: IP67/IP69K Ignition Protection: ISO-8846 / UL 1500 Minimum Operate Temp. (Deg C): -40 C Max Operate Temp. (Deg C): 85 Focal Features:Sealed EnclosureHermetically sealed against dust and moisture penetration. The high temperature rating for all installation locations.18-8 Stainless Steel Self-Locking HardwareIt resists corrosion and ensures long-term connection reliability with premium hardware.Easy MountingReinforced mounting holes provide secure installation and easy attachment for the installer.Remote Status SupportOptional auxiliary contacts that support remote status indication. Normalized SKU: 7024UPC Code: 850035199787Egis 7024 Literature Download Quick Reference Guide Owners Manual

Download LiteratureEgis 7021 ComponentsContactor 250A, 12/24VThis 250A Egis contactor is perfect for reducing installation costs and weight by eliminating large cable runs to manual switches through robust remote switching of high-ampere engines and auxiliary loads.Applications: Ensure flawless operation for the life of the installation with a hermetically sealed contactor sealed against dust & moisture Intrusion. High Contact Voltage Rating easily supports 12 or 24 Vdc control voltage applications while also supporting higher switching voltage applications up to 48 V and well beyond. Features: Ignition is protected and safe for installation in closed compartments with potential explosive gases High Electrical Switching Endurance delivers 6,000 cycles at 250A or 450V and 100,000 cycles at 250A/14V High Interrupt Current Capability - safely able to open in a locked starter situation (up to 1,500 A @ 14 Vdc) Bullet-proof Construction - sealed device, high-temperature materials for engine compartment applications, and stainless self-locking hardware. 4 Year Industry Leading Warranty   Specifications: Continuous Current (Amps): 250/500 Operation Control Voltage: 9-36 VDC Ingress Protection: IP67/IP69K Ignition Protection: ISO-8846 / UL 1500 Electrical Endurance Rating (Cycles): 1,000,000 Minimum Operate Temp. (Deg C): -40 C Max Operate Temp. (Deg C): 85 Focal Features:Sealed EnclosureHermetically sealed against dust and moisture penetration. The high temperature rating for all installation locations.18-8 Stainless Steel Self-Locking HardwareResists corrosion and ensures long-term connection reliability with premium hardware.High Interrupt CapabilitySafely able to open in a locked starter situation up to 1,500 A @14 Vdc.Easy MountingReinforced mounting holes provide secure installation and easy attachment for the installer. Normalized SKU: 7021UPC Code: 850035199671Egis 7021 Literature Download Quick Reference Guide Owners Manual

Newmar BX-1 ComponentsBX-1 Junction BoxThis BX Series splashproof box provides secure, protected wiring connections in wheelhouses or below decks and engine rooms. Features: IP rating 54 – “Splashproof” Rugged cast aluminum box with white enamel finish Metal box reduces electrical interference Easy wiring access through multiple grommeted cable entries Supplied with high-quality connector strips – secure wires with compression fittings – no terminals required – see matrix below for connector strips specifications per box Specifications: Number of Connector Strips: 1 Positions per Strip: 6 Max Wire Gauge: 16 Max Amps (per position): 6  Cable Entries: 2  Cable Diameter: 0.25 in. Box Size: 2 x 2 x 1.2 in. Box Size: 5.1 x 5.1 x 3.1 cm Normalized SKU: BX1

Lumitec 101829 ComponentsPico OHM Expansion ModuleThe Pico OHM modules make it easy to connect 4-wire RGB accessories to a standard 2-wire DC electrical system and control the color output through a Poco Digital Controller.Features: Connect RGB accessories to a standard 2-Wire DC electrical system 4 Modules in the pack RGB only (no RGBW) 12VDC ONLY (0.4A max current draw) No TTP (Timed Toggle Protocol) Lumitec Digital Controller (POCO) is required to control Pico OHM Normalized SKU: 101829UPC Code: 089300018298

Sierra FS46580 Components Insulated dual stud post with isolating plate Designed to provide a termination point allowing the extension of harnesses & other wires Securely connects heavy-duty, high-amperage cables An insulated base ensures no leakage to metal hulls Glass Fiber reinforced Nylon base ensures great mechanical strength and durability 48VDC Max Operating Voltage Stud Size: M10 (Replaces 3/8) Interchange: Blue Sea: 2017 Normalized SKU: FS46580UPC Code: 808282382070

Sierra FS46570 Components An insulated single stud post is designed to terminate heavy-duty cables for one or more connections. Securely connects heavy-duty, high-amperage cables An insulated base ensures no leakage to metal hulls Stud Size: M8 (Replaces 5/16) Glass Fiber reinforced Nylon base ensures great mechanical strength and durability 48VDC Max Operating Voltage Interchange: Blue Sea: 2002 Normalized SKU: FS46570UPC Code: 808282382223
