Download LiteratureMastervolt 77020115 Charger AccessoriesMasterShunt 500 CZoneMasterShunt is the heart of every battery powered energy system. This integrated battery monitor shares information about the battery bank with other MasterBus, CZone or NMEA 2000 enabled devices such as battery chargers, inverter/chargers and displays. No surprises: allowing complete automation of your system, MasterShunt improves comfort, prolongs battery life and extends your runtime.The MasterShunt 500 provides all information needed for monitoring your battery bank and control of your system, such as voltage, current, state of charge and time remaining. All information is made available to the system by a single MasterBus or CZone cable. Extremely accurate measurement of current flow over state of charge enables the MasterShunt to precisely determine the time remaining.Programmable events and an integrated real time clock make it possible to fully automate your system. Examples are to start your generator automatically when the battery bank is low (or just delaying at night!), or to automatically generate a warning at a certain depth of discharge. The proven MasterShunt design has been upgraded to obtain an even higher level of accuracy and control. Taking into account battery specific parameters, MasterShunt takes reading accuracy to a whole new level.The MasterShunt 500 CZone allows freedom of choice with regards to fuse type, rating and location. The battery monitor is supplied with an internal bus bar, to be used in situations where an external fuse holder is selected. In case the MasterShunt is installed close to the battery, the bus bar may be replaced by either an ANL type or Class T main fuse, saving both space and cost.Features: MasterBus, CZone and NMEA 2000 communication. Fits in a CZone system including setup tools and configuration file. Digital shunt providing the energy system with extensive information and historical data. Very accurate and reliable determination of State of Charge (SOC). Service mode prevents memory loss during system maintenance. Realistic and precise indication of the time remaining. For higher current, multiple MasterShunt models may be installed in parallel. MasterConnect system makes connecting to the DC Distribution product very easy. Straight forward, easy to install. Freedom of choice for fuse type, rating and location. Suitable for T-fuse and ANL-fuse (to be ordered separately). Robust housing with isolation of the DC connections. Applications:Any application in marine, mobile, industrial, infrastructure where batteries need to be monitored for increased reliability, battery life, comfort and runtime. Normalized SKU: 77020115UPC Code: 816882022517Mastervolt 77020115 Literature Download Owners Manual

Victron Energy BPP900100200 Charger AccessoriesCCGX Wi-Fi Module Simple (Nano USB)Use to connect a Victron Color Control GX to a wireless network.  Enter the wireless ID and Passwords using the Color Control GX.Features: USB 2.0 interface Data rate 802.11n, 802.11g, 802.11b Frequency band 2.4 GHz Normalized SKU: BPP900100200UPC Code: 8719076021377

Victron Energy BAM010702200R Charger AccessoriesBattery Monitor - BMV-702 - BlackFeatures: Battery ‘fuel gauge’, time-to-go indicator, and much more The remaining battery capacity depends on the ampere-hours consumed, discharge current, temperature and the age of the battery. Complex software algorithms are needed to take all these variables into account. Next to the basic display options, such as voltage, current and ampere-hours consumed, the BMV-700 series also displays state of charge, time to go, and power consumption in Watts. The BMV-702 features an additional input which can be programmed to measure the voltage (of a second battery), battery temperature or midpoint voltage (see below).  Bluetooth Smart Use the Bluetooth Smart dongle to monitor your batteries on Apple or Android smartphones, tablets, macbooks and other devices.  Easy to install All electrical connections are to the quick connect PCB on the current shunt. The shunt connects to the monitor with a standard RJ12 telephone cable. Included: RJ 12 cable (10 m) and battery cable with fuse (2 m); no other components needed. Also included are a separate front bezel for a square or round display appearance, a securing ring for the rear mounting and screws for the front mounting.  Easy to program (with your smartphone!) A quick install menu and a detailed setup menu with scrolling texts assist the user when going through the various settings. Alternatively, choose the fast and easy solution: download the smartphone app (Bluetooth Smart dongle needed)  Standard features - Battery voltage, current, power, ampere-hours consumed and state of charge - Remaining time at the current rate of discharge - Programmable visual and audible alarm - Programmable relay, to turn off non critical loads or to run a generator when needed - 500 Amp quick connect shunt and connection kit - Shunt selection capability up to 10.000 Amps - VE.Direct communication port - Stores a wide range of historical events, which can be used to evaluate usage patterns and battery health - Wide input voltage range: 6,5 – 95V - High current measurement resolution: 10 mA (0,01A) - Low current consumption: 2,9Ah per month (4mA) @12V and 2,2Ah per month (3mA) @ 24V Normalized SKU: BAM010702200RUPC Code: 8719076020127

Victron Energy BAM010700000R Charger AccessoriesBMV-700 Battery MonitorThe BMV-700 is a high precision battery monitor. The essential function of a battery monitor is to calculate ampere hours consumed and the state of charge of a battery. Ampere hours consumed are calculated by integrating the current flowing in or out of the battery.Features: Battery voltage, current, power, ampere-hours consumed and state of charge  Remaining time at the current rate of discharge  Programmable visual and audible alarm  Programmable relay, to turn off non critical loads or to run a generator when needed  500 Amp quick connect shunt and connection kit  Shunt selection capability up to 10.000 Amps  VE.Direct communication port  Stores a wide range of historical events, which can be used to evaluate usage patterns and battery health  Wide input voltage range: 6,5 – 95V  High current measurement resolution: 10 mA (0,01A)  Low current consumption: 2,9Ah per month (4mA) @12V and 2,2Ah per month (3mA) @ 24V VictronConnectVictronConnect lets you get live status information and configure any Victron products which either have Bluetooth built-in, or are connected to a VE.Direct Bluetooth Smart Dongle. Normalized SKU: BAM010700000RUPC Code: 8719076020073

Xantrex 808-1802 Charger AccessoriesPROsine Remote LCD PanelThis remote panel displays DC input voltage from the battery, DC input current (amps) drawn from the battery, power scale with inverter wattage output, and status/error display for shutdown conditions - overload, over-temperature, and over/under voltage. Comes with 25' (7.6M) cable.NOTE: This accessory is included with PROsine inverters.WARNING: This product can expose you to chemicals including Diisononyl Phthalate (DINP) which is known to the State of California to cause cancer, and Di-isodecyl Phthalate (DIDP) which is known to the State of California to cause reproductive harm. For more information go to P65Warnings.ca.gov. Normalized SKU: 8081802

Victron Energy BAM010702000R Charger AccessoriesBattery Monitor - BMV-702 - GreyFeatures: Battery ‘fuel gauge’, time-to-go indicator, and much more The remaining battery capacity depends on the ampere-hours consumed, discharge current, temperature and the age of the battery. Complex software algorithms are needed to take all these variables into account. Next to the basic display options, such as voltage, current and ampere-hours consumed, the BMV-700 series also displays state of charge, time to go, and power consumption in Watts. The BMV-702 features an additional input which can be programmed to measure the voltage (of a second battery), battery temperature or midpoint voltage (see below).  Bluetooth Smart Use the Bluetooth Smart dongle to monitor your batteries on Apple or Android smartphones, tablets, macbooks and other devices.  Easy to install All electrical connections are to the quick connect PCB on the current shunt. The shunt connects to the monitor with a standard RJ12 telephone cable. Included: RJ 12 cable (10 m) and battery cable with fuse (2 m); no other components needed. Also included are a separate front bezel for a square or round display appearance, a securing ring for the rear mounting and screws for the front mounting.  Easy to program (with your smartphone!) A quick install menu and a detailed setup menu with scrolling texts assist the user when going through the various settings. Alternatively, choose the fast and easy solution: download the smartphone app (Bluetooth Smart dongle needed)  Standard features - Battery voltage, current, power, ampere-hours consumed and state of charge - Remaining time at the current rate of discharge - Programmable visual and audible alarm - Programmable relay, to turn off non critical loads or to run a generator when needed - 500 Amp quick connect shunt and connection kit - Shunt selection capability up to 10.000 Amps - VE.Direct communication port - Stores a wide range of historical events, which can be used to evaluate usage patterns and battery health - Wide input voltage range: 6,5 – 95V - High current measurement resolution: 10 mA (0,01A) - Low current consumption: 2,9Ah per month (4mA) @12V and 2,2Ah per month (3mA) @ 24V Normalized SKU: BAM010702000RUPC Code: 8719076020103

Victron Energy ASS030140000 Charger AccessoriesInterface MK3-USB (VE. BUS to USB) ModuleThe MK3-USB allows the following products to connect to a computer for configuration and firmware updates:Multi, MultiGrid, MultiPlus, MultiPlus-II, Quattro, Inverter/Charger settings in ECOmulti, EasySolar, EasyPlus, and Inverters with a VE.Bus communication port Normalized SKU: ASS030140000UPC Code: 8719076019435

Victron Energy SBS050150200 Charger AccessoriesSmart Battery Sense Long Range (Up to 10M)The VE.Bus Smart dongle is a Bluetooth Smart enabled VE.Bus interface, with battery temperature-and-voltage sensing. It communicates system information straight to your smart phone - using the free-to-use VictronConnect app.  When used with Multi- inverter/chargers the dongle provides on-battery temperature and voltage sensing capabilities - allowing compensation for possible cable losses which can occur during charging and discharging. Temperature sensing allows accurate temperature-compensation during battery charge cycles. The dongle is, at present, the only way to add an “on-battery” sensing capability to the MultiPlus-II models, if they are not also connected to a GX device and CANbus battery.The dongle can be used in systems with or without a GX device - such as the CCGX. In systems with a GX device, and another source of temperature and voltage data (eg from a CANbus battery), the CCGX data will override temperature and voltage information from the dongle. In this role the dongle will still provide live-information via its VictronConnect interface; and it will provide firmware updates without requiring an internet connection.When the dongle is used in systems which do not have a GX device, the dongle's voltage and temperature data becomes the primary source of that information, and can be used by other connected devices for voltage compensation.In systems with a Multiplus-II, dongle and GX device, but no other source of temperature and voltage, the data from the dongle will also be used.At this time, the VE.Bus Smart dongle cannot send its temperature and voltage data as part of a VE.Smart network.The VE.Bus Smart dongle is able to sense battery temperature in two ways: The default method is the dongle's on-board temperature sensor. When the dongle is mounted directly onto the battery case (using its adhesive attachment) it will sense the battery temperature directly from the battery casing. The second method - which provides improved battery temperature sensing - is available by using an optional battery-terminal mounted sensor. When this sensor is connected, the default sensor is overridden and the dongle will use this method instead.What's in the Box? VE.Bus Smart Dongle Red battery (+) connection wire with 10mm eyelet and inline fuse. Black battery (-) connection wire with 10mm eyelet Connector block with screw terminals Specifications:Type = NONENormalized SKU: SBS050150200UPC Code: SBS050150200

Victron Energy REC020005010 Charger AccessoriesDigital Multi Control 200/200AThis panel is intended both for Multis and Quattros. It allows PowerControl and PowerAssist current limit setting for two AC sources: a generator and shore side current for example. Setting range: up to 200 Amps. The brightness of the LEDs is automatically reduced during night time. Normalized SKU: REC020005010UPC Code: REC020005010

Victron Energy DMC000200010R Charger AccessoriesDigital Multi Control 200/200A GXThe Digital Multi Control is used to remotely view and adjust AC input currents, and turn on and off the Multi or Quattro. It is designed to integrate cleanly with your boat, vehicle or house system control panel.The Digital Multi Control panel (DMC) is designed to work with all Multi/Quattro. This includes stand alone, parallel and 2-3 phase configurations. Connecting the DMC to your system is simple, in most cases just connecting the DMC with an RJ45 cable is sufficient and no extra set-up handling is required. Normalized SKU: DMC000200010RUPC Code: DMC000200010

Victron Energy BPP900400100 Charger AccessoriesVenus GX Control - No DisplayFeatures: Venus GX The Venus GX provides intuitive control and monitoring for all Victron power systems. The list of Victron products that can be connected is endless: Inverters, Multis, Quattros, MPPT solar chargers, BMV battery monitors, Lynx Ion + Shunt and more.  VRM Online Portal All readings are forwarded to our free remote monitoring website: the VRM Online Portal. To get an impression, try the demo on https://vrm.victronenergy.com. See also the screenshots below.  Remote Console on VRM The way to access the device for setting up, as well as monitoring, is via Remote Console. Either via VRM, via the built-in WiFi Access Point, or on the local LAN/WiFi network.  Automatic genset start/stop A highly customizable start/stop system. Use state of charge, voltage, load and other parameters. Define a special set of rules for quiet times, and optionally a monthly test run.  Data logging When connected to the internet, all data is sent to the VRM Portal. When there is no internet connection available, the Venus GX will store the data internally, up to 48 hours. By inserting a micro SD-card or USB stick, more data can be stored. These files can then be uploaded to the VRM Portal, or offline converted with the VictronConnect app, for analysis. Supported products - Multis and Quattros, including split-phase and three-phase systems. Monitoring and control (on/off and current limiter). Changing configuration is possible (only remotely via the internet, not without an internet connection). - EasySolar 1600VA - BlueSolar MPPT Solar Chargers with a VE.Direct port. - BlueSolar MPPT 150/70 and the MPPT 150/85 with VE.Can port. - SmartSolar MPPT 150/70 and the MPPT 150/100 with VE.Can port. When multiple BlueSolar MPPTs or SmartSolar MPPTs with VE.Can are used in parallel, all the information is combined as one. See also our blog-post about synchronizing multiple MPPT 150/70 solar chargers. - BMV-700 family can be connected directly to the VE.Direct ports on the Venus GX. Use the VE.Direct Cable for this. - BMV-600 family can be connected to the VE.Direct ports on the Venus GX. Requires an accessory cable. - Lynx Ion + Shunt - Lynx Ion BMS - Lynx Shunt VE.Can - Skylla-i battery chargers - NMEA2000 tank sensors - A USB GPS can be connected to the USB port. The data is sent to the VRM Portal for tracking purposes. The map on VRM will show the latest position. - Fronius PV Inverters When more than two VE.Direct products must be connected, USB can be used. Normalized SKU: BPP900400100UPC Code: BPP900400100
