Newmar AC-IX Breaker Panels"AC Master panels Essential control/protection whenever AC from shorepower or generators is on board. A double pole master breaker with power on indicator light protects both hot and neutral legs of the AC circuit. A reverse polarity light provides clear warning when wiring is reversed and poses a shock hazard. Single pole branch circuit breakers (Model AC-IX) and individual ?ON? indicator lights provide control and protection of various AC loads. For 115/230 VAC applications ? see ratings note. A label set of common on-board circuits is provided. AC-IX: 30 amp master breaker , 5 branch circuit capacity 4 installed standard 1-10A, 2-15A, 1-20A, or specify. LS-I Label set included. Panel size: 5 1/4" x 7 1/2", (13.3 X 9.5 cm.,) Weight: 2 lbs., (.9 Kg.) AC-II: 30 Amp master breaker. Panel size: 5 1/4" x 3 3/4" (13.3 X 9.5 cm.), Weight: 1 lb (.5 Kg.) Model Inches Centimeters AC-IX 4 X 6 10.2 X 15.2 AC-II 4 X 2.5 10.2 X 6.4 "Normalized SKU: ACIX

Newmar ACCY-IBX Breaker Panels"Accessory Panels These versatile panels are ideal for smaller vessels with only a limited number of electrical circuits, or for larger systems where their modular design makes for an easy and attractive expansion of existing system capacity. Stock panels with breakers installed come standard with DC indicator lights, but may be factory modified with AC indicator lights instead. Blank versions of the panels come with all necessary hardware to install lights and breakers. All panels are provided with a circuit identification label set of 22 common on-board electrical functions (see below). ACCY-IX: 8 breaker capacity, 5 installed standard; 2-5A, 1-10A, 1-15A, 1-20A or specify. 8 DC circuit "ON" indicator lights installed standard, AC lights optional. Size: 7 1/2" x 5 1/4", Weight: 2 lbs. ACCY-IBX: Blank version of ACCY-IX above. No breakers provided. Label set, light and breaker mounting hardware provided. Weight: 1 lb.    Half-height version of ACCY-IX at left. 3 breaker capacity, 3 installed standard; 3 DC ?ON? indicator lights installed standard - AC optional. 1-5A, 1-10A 1-15A or specify. Size: 3 3/4" x 5 1/4", Weight: 1 lb. ACCY-IIBX: Blank version of ACCY-IIX above. No breakers or lights provided. Label set, light and breaker mounting hardware provided. Weight: 1 lb.  Installation Cut-Out Dimensions* Model Inches (W x H) ACCY-IX 4 X 6 ACCY-IBX 4 X 6 ACCY-IIBX 4 X2.5 * Allow approximately 3" depth clearance for all panels on this page. Label Set Provided LS-I Standard Set 22 Labels   ACCESSORY AFT CABIN ANCHOR BILGE PUMP BOW CABIN LIGHTS ENGINE ROOM    FORE CABIN MAIN CABIN MAST NAV/COM OUTLETS REFRIGERATOR RUNNING   SPARE SPREADER SUMP PUMP WATER HEATER WATER PRESSURE WINDLASS WINDSHIELD "Normalized SKU: ACCYIBX

Newmar ACCY-IX Breaker Panels"Accessory Panels These versatile panels are ideal for smaller vessels with only a limited number of electrical circuits, or for larger systems where their modular design makes for an easy and attractive expansion of existing system capacity. Stock panels with breakers installed come standard with DC indicator lights, but may be factory modified with AC indicator lights instead. Blank versions of the panels come with all necessary hardware to install lights and breakers. All panels are provided with a circuit identification label set of 22 common on-board electrical functions (see below). ACCY-IX: 8 breaker capacity, 5 installed standard; 2-5A, 1-10A, 1-15A, 1-20A or specify. 8 DC circuit "ON" indicator lights installed standard, AC lights optional. Size: 7 1/2" x 5 1/4", Weight: 2 lbs. ACCY-IBX: Blank version of ACCY-IX above. No breakers provided. Label set, light and breaker mounting hardware provided. Weight: 1 lb.    Half-height version of ACCY-IX at left. 3 breaker capacity, 3 installed standard; 3 DC ?ON? indicator lights installed standard - AC optional. 1-5A, 1-10A 1-15A or specify. Size: 3 3/4" x 5 1/4", Weight: 1 lb. ACCY-IIBX: Blank version of ACCY-IIX above. No breakers or lights provided. Label set, light and breaker mounting hardware provided. Weight: 1 lb.  Installation Cut-Out Dimensions* Model Inches (W x H) ACCY-IX 4 X 6 ACCY-IBX 4 X 6 ACCY-IIBX 4 X2.5 * Allow approximately 3" depth clearance for all panels on this page. Label Set Provided LS-I Standard Set 22 Labels   ACCESSORY AFT CABIN ANCHOR BILGE PUMP BOW CABIN LIGHTS ENGINE ROOM    FORE CABIN MAIN CABIN MAST NAV/COM OUTLETS REFRIGERATOR RUNNING   SPARE SPREADER SUMP PUMP WATER HEATER WATER PRESSURE WINDLASS WINDSHIELD "Normalized SKU: ACCYIXUPC Code: 020-0008-9

Sea-Dog 422800-1 Breaker PanelsAluminum Circuit Breaker Panel - 6 CircuitAluminum Breaker Panel features six 15A 12VDC illuminated SPST On/Off rocker switches and six thermal AC/DC circuit breakers (two 3A, two 6A, one 8A, and one 10A). Individual circuit 10A max. 40A total. 12VDC. Includes a sheet of 20 preprinted decals to customize to your specific applications. Constructed of stamped anodized aluminum. Installs with six #6 RH fasteners (not included). WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Seadog Alumunim Circuit Breaker Panel Six 422800-1Normalized SKU: 4228001UPC Code: 035514423410

Sea-Dog 424636-1 Breaker PanelsWater Resistant Toggle Switch Panel Water Resistant Toggle Switch Panel is constructed of injection molded ABS and polycarbonate. Features six 15A 12VDC toggle switches with blue LED indicator lights, ATC fuse holders, and decal sheet. Rated IP66. WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Normalized SKU: 4246361UPC Code: 035514428903

Sea-Dog 424627-1 Breaker PanelsWater Resistant Toggle Switch Panel with LED Power Socket - 5 ToggleWater Resistant Toggle Switch Panel is constructed of injection molded ABS and polycarbonate. Features five 15A 12VDC toggle switches with blue LED indicator lights, blue LED lighted power socket, ATC fuse holders, and decal sheet. Rated IP66.WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Normalized SKU: 4246271UPC Code: 035514428880

Sea-Dog 424623-1 Breaker PanelsWater Resistant Toggle Switch Panel with LED Power Socket - 3 Toggle Water Resistant Toggle Switch Panel is constructed of injection molded ABS and polycarbonate. Features three 15A 12VDC toggle switches with blue LED indicator lights, blue LED lighted power socket, ATC fuse holders, and decal sheet. Rated IP66.WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Normalized SKU: 4246231UPC Code: 035514428897

Sea-Dog 424617-1 Breaker PanelsWater Resistant Toggle Switch Panel with USB Power Socket - 5 Toggle Water Resistant Toggle Switch Panel is constructed of injection molded ABS and polycarbonate. Features five 15A 12VDC toggle switches with blue LED indicator lights, blue LED lighted double USB power socket, ATC fuse holders, and decal sheet. USB power socket output is 4.8A, 2.4A per side. Rated IP66.WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Normalized SKU: 4246171UPC Code: 035514428811

Blue Sea System 4369 Breaker PanelsWater Resistant USB Accessory Panel - 15A Circuit Breaker, 4x Blank Apertures Easy to install accessory panels include a 15A circuit breaker switch and pre-wired harness. Panels offer customizable 12V charging and monitoring options.Features: Pre-wired harness included in all panels for easy installation Silicon breaker boots and gasket protects against water ingress Illuminated Carling Technologies 15A circuit breaker switch allows the ability to shut off panel preventing parasitic draw Polycarbonate/ABS panel face is UV-stabilized, flame retardant, and will not corrode 12V DC only Specifications: Positions: 1 Nominal Voltage: 12V DC Normalized SKU: 4369UPC Code: 632085043698

Blue Sea System 3118 Breaker PanelsSMS Surface Mount System Panel Enclosure - 120V AC / 50A ELCI Main - 2 Blank Circuit PositionsPanel enclosure for ELCI Main circuit breakers and other large frame devices. Meets ABYC E-11 when used with an ELCI Main circuit breaker and mounted within 10 feet of the shore power inletFeatures: Includes one 120V AC / 50A ELCI Main and two blank positions Blank apertures for custom breaker loading Glass filled polycarbonate mounting box Clear cover allows easy view of circuit breaker status Overlapping cover for strength and increased gasket protection Oversized, formed in place seamless PUR gasket Easily removable stainless steel hinge pin for unobstructed installation Stainless steel latch secures cover without penetrating the enclosure Blank circuit positions accommodate Carling Technologies™ A- and C- Series Flat Rocker and ELCI Main circuit breakers Stainless steel mounting hardware included Includes waterproof glands LED lights for back lighting and ON indication Specifications: Minimum Operating Temperature: -40° C Maximum Operating Temperature: 85° C Cover Screws and Hardware: 10-32 Stainless Steel Enclosure Size: 6.0" x 6.0" x 4.0" (152mm x 152mm x 102mm) Exterior Overall Dimensions: 7.6" x 7.4" x 4.7" (192mm x 188mm x 120mm) Mounting Hardware: 1/4" Diameter, #12 (6 mm) Weight: 5.25lb (2.38 kg) WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications:AC/DC = NONE Breaker Quantity - Max = NONE Fuses/Amps/Volts = NONE Meters = NONE Switches/Amps/Volts = NONENormalized SKU: 3118UPC Code: 632085031183

Blue Sea System 3116 Breaker PanelsSMS Surface Mount System Panel Enclosure - 120V AC / 30A ELCI Main - 3 Blank Circuit PositionsPanel enclosure for ELCI Main circuit breakers and other large frame devices. Meets ABYC E-11 when used with an ELCI Main circuit breaker and mounted within 10 feet of the shore power inletFeatures: Includes one 120V AC / 30A ELCI Main and three blank positions Blank apertures for custom breaker loading Glass filled polycarbonate mounting box Clear cover allows easy view of circuit breaker status Overlapping cover for strength and increased gasket protection Oversized, formed in place seamless PUR gasket Easily removable stainless steel hinge pin for unobstructed installation Stainless steel latch secures cover without penetrating the enclosure Blank circuit positions accommodate Carling Technologies™ A- and C- Series Flat Rocker and ELCI Main circuit breakers Stainless steel mounting hardware included Includes waterproof glands LED lights for back lighting and ON indication Specifications: Minimum Operating Temperature: -40° C Maximum Operating Temperature: 85° C Cover Screws and Hardware: 10-32 Stainless Steel Enclosure Size: 6.0" x 6.0" x 4.0" (152mm x 152mm x 102mm) Exterior Overall Dimensions: 7.6" x 7.4" x 4.7" (192mm x 188mm x 120mm) Mounting Hardware: 1/4" Diameter, #12 (6 mm) Weight: 4.15lb (1.88 kg) WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications:AC/DC = NONE Breaker Quantity - Max = NONE Fuses/Amps/Volts = NONE Meters = NONE Switches/Amps/Volts = NONENormalized SKU: 3116UPC Code: 632085031169

Blue Sea System 3117 Breaker PanelsSMS Surface Mount System Panel Enclosure - 2 x 120V AC / 30A ELCI MainPanel enclosure for ELCI Main circuit breakers and other large frame devices. Meets ABYC E-11 when used with an ELCI Main circuit breaker and mounted within 10 feet of the shore power inletFeatures: Includes one Dual 120V AC / 30A ELCI Main Glass filled polycarbonate mounting box Clear cover allows easy view of circuit breaker status Overlapping cover for strength and increased gasket protection Oversized, formed in place seamless PUR gasket Easily removable stainless steel hinge pin for unobstructed installation Stainless steel latch secures cover without penetrating the enclosure Stainless steel mounting hardware included Includes waterproof glands LED lights for back lighting and ON indication Specifications: Minimum Operating Temperature: -40°C Maximum Operating Temperature: 85°C Cover Screws & Hardware: 10-32 Stainless Steel Enclosure Size: 6.0" x 6.0" x 4.0" Exterior Overall Dimensions: 7.6" x 7.4" x 4.7" Mounting Hardware: 1/4" Diameter, #12 (6mm) Weight: 6.5lbs WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications:AC/DC = AC Breaker Quantity - Max = NONE Fuses/Amps/Volts = NONE Meters = NONE Switches/Amps/Volts = NONENormalized SKU: 3117UPC Code: 632085031176
