Raymarine E70372-00-102 ChartplottersRaymarine Axiom Pro 12RVX 12" MFD With RealVision 3D and 1kW CHIRP and Lighthouse NC3 North America Lakes and Coastal tide StationsModel: E70372-00-102 RealVision 3D True 1kW CHIRP Sonar Scroll Back HybridTouch™ Quad Core Processor Optical Bonding Technology & IPS Displays IP & Analog Video Clear Cruise™ Quantum CHIRP, HD & SHD NMEA2000 & NMEA0183 Specifications Display Size 12.1" IPS Optically Bonded LCD Display Resolution 1280 x 800 WXGA Display Type Multitouch Brightness 1,200 nits Viewing Angle Degrees: 88 / 88 / 88 / 88 (Top / Bottom / Left / Right) Mounting Top, Front, Bracket Waterproof Rating IPX6 / IPX7 Operating Temp minus 13deg F to 131deg F (-25deg C to +55deg C) Storage Temp minus 22deg F to 158deg F (-30deg C to +70deg C) Sensors Sonar Type - Built-in RealVision 3D, 1kw CHIRP sonar Sonar Connections 25pin connector used only with CPT-S transducers, Pro S can only be used with CPT-S transducers that also connect directly to CP470 sonar module. Requires A80490 adaptor cable. Sonar Depth CHIRP Sonar = 900 feet (974 m)DownVision™ = 600 feet (183 m) External Sonar Yes - CP100, CP200, CP370, CP470, CP570 via RayNet Radar Yes - Quantum, Digital, HD Color and Super HD Color Radars AIS Yes - N2K compatible GNSS / GPS Built-in GNSS Receiver: GPS/GLONASS/Galileo/Beidou - 10Hz 72 Channel - External Accessory: GA150 (A80288) Autopilot Control Yes - Evolution Autopilot Thermal Night Vision Yes - IP or Analogue Video / Camera 1 x Analogue input (BNC) Up to 10 IP Cameras Weather GRIB View - Free GRIB viewer and Theyr Ltd Subscription - SiriusXM - N. America Only Audio N2K / *Bluetooth / *SiriusXM Audio [*Available in future Lighthouse 3 software update] Digital Switching Yes - Empirbus & C-Zone compatible [C-Zone integration available in future Lighthouse 3 software update] Remote Control RMK-10 (A80438) & RCU-3 (E62351) Networking Ethernet 2 x 10/100/1000 Mbits/ Network (RayNet) NMEA0183 1 Transmit / 2 Receive NMEA2000 1 x NMEA2000 port (DeviceNet microC) SeaTalkNG Requires DEVICENET FEMALE (F) ADAPTOR CABLE (A06079 100mm adaptor included in box) USB 1 x USB microAB (rear - charging, external storage device or RCR-SD/USB Accessory (A80440) Wi-Fi WiFi - 802.11 a / b / g / n BlueTooth Bluetooth 4.0 + Low Energy + Power Class 1.5 [Available in future Lighthouse 3 software update] Navigation Cartography Lighthouse, Navionics, *C-MAP Essentials & *C-MAP 4D MAX+ [*C-MAP chart compatibility available in future Lighthouse 3 software update] Waypoint/Routes/Tracks (Wpts/Rts/Trk) 10,000 wpts / 200 wpt groups / 150 rts - 250 wpt max / 16 tracks - 10,000 max trk pts MEMORY Internal 16GB Solid State 16GB Solid State 2 x microSD slots (front) - microSDHC max 32GB NTFS or FAT32 format / microSDXC max 2TB NTFS or FAT32 format (microSD native format of exFAT must be reformatted to NTFS or FAT32) Input Voltage 12V and 24V DC (8 V to 32 DC) Input Draw ~35W Dimensions 14.1" x 9.17" x 2.56" (358 x 223 x 65 mm) What's in the Box: Axiom Pro 12RVX Trim Kit Suncover Trunnion Kit PWR/VIDEO/NMEA0183 CBL, STRT 1.5M Mounting Hardware Mounting Template Quick Start Guide Warranty Card Raymarine window decal Lighthouse NC3 North America Lakes and Coastal tide Stations microSD Normalized SKU: E7037200102UPC Code: 723193838211

Raymarine E70482-00-102 ChartplottersRaymarine Axiom Pro 12S 12" MFD With Single Channel CHIRP and Lighthouse NC3 North America Lakes and Coastal Tide StationsModel: E70482-00-102 High CHIRP NMEA2000 & NMEA0183 Sonar Scroll Back HybridTouch™ Quad Core Processor Optical Bonding Technology & IPS Displays IP & Analog Video Clear Cruise™ Quantum CHIRP, HD & SHD NMEA2000 & NMEA0183 Specifications Display Size 12.1" IPS Optically Bonded LCD Display Resolution 1280 x 800 WXGA Display Type Multitouch Brightness 1,200 nits Viewing Angle Degrees: 88 / 88 / 88 / 88 (Top / Bottom / Left / Right) Mounting Top, Front, Bracket Waterproof Rating IPX6 / IPX7 Operating Temp minus 13deg F to 131deg F (-25deg C to +55deg C) Storage Temp minus 22deg F to 158deg F (-30deg C to +70deg C) Sensors Sonar Type - Built-in High CHIRP Sonar Connections 25pin connector used only with CPT-S transducers, Pro S can only be used with CPT-S transducers that also connect directly to CP470 sonar module. Requires A80490 adaptor cable. Sonar Depth CHIRP Sonar = 900 feet (974 m)DownVision™ = 600 feet (183 m) External Sonar Yes - CP100, CP200, CP370, CP470, CP570 via RayNet Radar Yes - Quantum, Digital, HD Color and Super HD Color Radars AIS Yes - N2K compatible GNSS / GPS Built-in GNSS Receiver: GPS/GLONASS/Galileo/Beidou - 10Hz 72 Channel - External Accessory: GA150 (A80288) Autopilot Control Yes - Evolution Autopilot Thermal Night Vision Yes - IP or Analogue Video / Camera 1 x Analogue input (BNC) Up to 10 IP Cameras Weather GRIB View - Free GRIB viewer and Theyr Ltd Subscription - SiriusXM - N. America Only Audio N2K / *Bluetooth / *SiriusXM Audio [*Available in future Lighthouse 3 software update] Digital Switching Yes - Empirbus & C-Zone compatible [C-Zone integration available in future Lighthouse 3 software update] Remote Control RMK-10 (A80438) & RCU-3 (E62351) Networking Ethernet 2 x 10/100/1000 Mbits/ Network (RayNet) NMEA0183 1 Transmit / 2 Receive NMEA2000 1 x NMEA2000 port (DeviceNet microC) SeaTalkNG Requires DEVICENET FEMALE (F) ADAPTOR CABLE (A06079 100mm adaptor included in box) USB 1 x USB microAB (rear - charging, external storage device or RCR-SD/USB Accessory (A80440) Wi-Fi WiFi - 802.11 a / b / g / n BlueTooth Bluetooth 4.0 + Low Energy + Power Class 1.5 [Available in future Lighthouse 3 software update] Navigation Cartography Lighthouse, Navionics, *C-MAP Essentials & *C-MAP 4D MAX+ [*C-MAP chart compatibility available in future Lighthouse 3 software update] Waypoint/Routes/Tracks (Wpts/Rts/Trk) 10,000 wpts / 200 wpt groups / 150 rts - 250 wpt max / 16 tracks - 10,000 max trk pts MEMORY Internal 16GB Solid State 16GB Solid State 2 x microSD slots (front) - microSDHC max 32GB NTFS or FAT32 format / microSDXC max 2TB NTFS or FAT32 format (microSD native format of exFAT must be reformatted to NTFS or FAT32) Input Voltage 12V and 24V DC (8 V to 32 DC) Input Draw ~35W Dimensions 14.1" x 9.17" x 2.56" (358 x 223 x 65 mm) What's in the Box: Axiom Pro 12S RayNet (F) to Raynet (F) Cable — 2M (A62361) Trunnion Cover Trunnion Knobs Trunnion Bracket Suncover (A80534) Power / Video / NMEA0183 Cable - Straight, 1.5M (R62379) Micro-C DeviceNet (F) to STNG (F) Cable - 1M (A06075) Panel Seal Gasket Bezel Pieces and Home / Menu Button Lighthouse NC3 North America Lakes and Coastal Tide Stations microSD Mounting Fixings Quick Start Guide Warranty Card Raymarine window decal Normalized SKU: E7048200102UPC Code: 723193838198

Raymarine E70373-00-102 ChartplottersRaymarine Axiom Pro 16RVX 15.6" MFD With RealVision 3D, 1kw CHIRP sonar and Lighthouse NC3 North America Lakes and Coastal Tide StationsModel: E70373-00-102 RealVision 3D, 1kw CHIRP sonar NMEA2000 & NMEA0183 Sonar Scroll Back HybridTouch™ Quad Core Processor Optical Bonding Technology & IPS Displays IP & Analog Video Clear Cruise™ Quantum CHIRP, HD & SHD NMEA2000 & NMEA0183 Specifications Display Size 15.6" IPS Optically Bonded LCD Display Resolution 1920 x 1080 FHD Display Type Multitouch Brightness 1,200 nits Viewing Angle Degrees: 88 / 88 / 88 / 88 (Top / Bottom / Left / Right) Mounting Top, Front, and optional RAM ball mount adapter Waterproof Rating IPX6 / IPX7 Operating Temp minus 13deg F to 131deg F (-25deg C to +55deg C) Storage Temp minus 22deg F to 158deg F (-30deg C to +70deg C) Sensors Sonar Type - Built-in RealVision 3D, 1kw CHIRP sonar Sonar Connections 25pin connector used only with CPT-S transducers, Pro S can only be used with CPT-S transducers that also connect directly to CP470 sonar module. Requires A80490 adaptor cable. Sonar Depth CHIRP Sonar = 900 feet (974 m)DownVision™ = 600 feet (183 m) External Sonar Yes - CP100, CP200, CP370, CP470, CP570 via RayNet Radar Yes - Quantum, Digital, HD Color and Super HD Color Radars AIS Yes - N2K compatible GNSS / GPS Built-in GNSS Receiver: GPS/GLONASS/Galileo/Beidou - 10Hz 72 Channel - External Accessory: GA150 (A80288) Autopilot Control Yes - Evolution Autopilot Thermal Night Vision Yes - IP or Analogue Video / Camera 1 x Analogue input (BNC) Up to 10 IP Cameras Weather GRIB View - Free GRIB viewer and Theyr Ltd Subscription - SiriusXM - N. America Only Audio N2K / *Bluetooth / *SiriusXM Audio [*Available in future Lighthouse 3 software update] Digital Switching Yes - Empirbus & C-Zone compatible [C-Zone integration available in future Lighthouse 3 software update] Remote Control RMK-10 (A80438) & RCU-3 (E62351) Networking Ethernet 2 x 10/100/1000 Mbits/ Network (RayNet) NMEA0183 1 Transmit / 2 Receive NMEA2000 1 x NMEA2000 port (DeviceNet microC) SeaTalkNG Requires DEVICENET FEMALE (F) ADAPTOR CABLE (A06079 100mm adaptor included in box) USB 1 x USB microAB (rear - charging, external storage device or RCR-SD/USB Accessory (A80440) Wi-Fi WiFi - 802.11 a / b / g / n BlueTooth Bluetooth 4.0 + Low Energy + Power Class 1.5 [Available in future Lighthouse 3 software update] Navigation Cartography Lighthouse, Navionics, *C-MAP Essentials & *C-MAP 4D MAX+ [*C-MAP chart compatibility available in future Lighthouse 3 software update] Waypoint/Routes/Tracks (Wpts/Rts/Trk) 10,000 wpts / 200 wpt groups / 150 rts - 250 wpt max / 16 tracks - 10,000 max trk pts MEMORY Internal 16GB Solid State 16GB Solid State 2 x microSD slots (front) - microSDHC max 32GB NTFS or FAT32 format / microSDXC max 2TB NTFS or FAT32 format (microSD native format of exFAT must be reformatted to NTFS or FAT32) Input Voltage 12V and 24V DC (8 V to 32 DC) Input Draw ~45W Dimensions 17.8" x 10.2" x2.72" (452 x 258 x 69 mm) What's in the Box: Axiom Pro 16RVX Trim Kit Suncover Trunnion Kit PWR/VIDEO/NMEA0183 CBL, STRT 1.5M Mounting Hardware Mounting Template Quick Start Guide Warranty Card Raymarine window decal Lighthouse NC3 North America Lakes and Coastal Tide Stations microSD Normalized SKU: E7037300102UPC Code: 723193838259

Raymarine E70483-00-102 ChartplottersRaymarine Axiom Pro 16S 15.6" MFD With Single Channel CHIRP and Lighthouse NC3 North America Lakes and Coastal Tide StationsModel: E70483-00-102 High CHIRP NMEA2000 & NMEA0183 Sonar Scroll Back HybridTouch™ Quad Core Processor Optical Bonding Technology & IPS Displays IP & Analog Video Clear Cruise™ Quantum CHIRP, HD & SHD NMEA2000 & NMEA0183 Specifications Display Size 15.6" IPS Optically Bonded LCD Display Resolution 1920 x 1080 FHD Display Type Multitouch Brightness 1,200 nits Viewing Angle Degrees: 88 / 88 / 88 / 88 (Top / Bottom / Left / Right) Mounting Top, Front, and optional RAM ball mount adapter Waterproof Rating IPX6 / IPX7 Operating Temp minus 13deg F to 131deg F (-25deg C to +55deg C) Storage Temp minus 22deg F to 158deg F (-30deg C to +70deg C) Sensors Sonar Type - Built-in High CHIRP Sonar Connections 25pin connector used only with CPT-S transducers, Pro S can only be used with CPT-S transducers that also connect directly to CP470 sonar module. Requires A80490 adaptor cable. Sonar Depth CHIRP Sonar = 900 feet (974 m)DownVision™ = 600 feet (183 m) External Sonar Yes - CP100, CP200, CP370, CP470, CP570 via RayNet Radar Yes - Quantum, Digital, HD Color and Super HD Color Radars AIS Yes - N2K compatible GNSS / GPS Built-in GNSS Receiver: GPS/GLONASS/Galileo/Beidou - 10Hz 72 Channel - External Accessory: GA150 (A80288) Autopilot Control Yes - Evolution Autopilot Thermal Night Vision Yes - IP or Analogue Video / Camera 1 x Analogue input (BNC) Up to 10 IP Cameras Weather GRIB View - Free GRIB viewer and Theyr Ltd Subscription - SiriusXM - N. America Only Audio N2K / *Bluetooth / *SiriusXM Audio [*Available in future Lighthouse 3 software update] Digital Switching Yes - Empirbus & C-Zone compatible [C-Zone integration available in future Lighthouse 3 software update] Remote Control RMK-10 (A80438) & RCU-3 (E62351) Networking Ethernet 2 x 10/100/1000 Mbits/ Network (RayNet) NMEA0183 1 Transmit / 2 Receive NMEA2000 1 x NMEA2000 port (DeviceNet microC) SeaTalkNG Requires DEVICENET FEMALE (F) ADAPTOR CABLE (A06079 100mm adaptor included in box) USB 1 x USB microAB (rear - charging, external storage device or RCR-SD/USB Accessory (A80440) Wi-Fi WiFi - 802.11 a / b / g / n BlueTooth Bluetooth 4.0 + Low Energy + Power Class 1.5 [Available in future Lighthouse 3 software update] Navigation Cartography Lighthouse, Navionics, *C-MAP Essentials & *C-MAP 4D MAX+ [*C-MAP chart compatibility available in future Lighthouse 3 software update] Waypoint/Routes/Tracks (Wpts/Rts/Trk) 10,000 wpts / 200 wpt groups / 150 rts - 250 wpt max / 16 tracks - 10,000 max trk pts MEMORY Internal 16GB Solid State 16GB Solid State 2 x microSD slots (front) - microSDHC max 32GB NTFS or FAT32 format / microSDXC max 2TB NTFS or FAT32 format (microSD native format of exFAT must be reformatted to NTFS or FAT32) Input Voltage 12V and 24V DC (8 V to 32 DC) Input Draw ~45W Dimensions 17.8" x 10.2" x2.72" (452 x 258 x 69 mm) What's in the Box: Axiom Pro 16S Trim Kit Suncover Trunnion Kit PWR/VIDEO/NMEA0183 CBL, STRT 1.5M Mounting Hardware Mounting Template Quick Start Guide Warranty Card Raymarine window decal Lighthouse NC3 North America Lakes and Coastal Tide Stations microUSB ,Raymarine Axiom Pro 16S 15.6" MFD With Single Channel CHIRP and Lighthouse NC3 North America Lakes and Coastal Tide StationsModel: E70483-00-102 High CHIRP NMEA2000 & NMEA0183 Sonar Scroll Back HybridTouch™ Quad Core Processor Optical Bonding Technology & IPS Displays IP & Analog Video Clear Cruise™ Quantum CHIRP, HD & SHD NMEA2000 & NMEA0183 Specifications Display Size 15.6" IPS Optically Bonded LCD Display Resolution 1920 x 1080 FHD Display Type Multitouch Brightness 1,200 nits Viewing Angle Degrees: 88 / 88 / 88 / 88 (Top / Bottom / Left / Right) Mounting Top, Front, and optional RAM ball mount adapter Waterproof Rating IPX6 / IPX7 Operating Temp minus 13deg F to 131deg F (-25deg C to +55deg C) Storage Temp minus 22deg F to 158deg F (-30deg C to +70deg C) Sensors Sonar Type - Built-in High CHIRP Sonar Connections 25pin connector used only with CPT-S transducers, Pro S can only be used with CPT-S transducers that also connect directly to CP470 sonar module. Requires A80490 adaptor cable. Sonar Depth CHIRP Sonar = 900 feet (974 m)DownVision™ = 600 feet (183 m) External Sonar Yes - CP100, CP200, CP370, CP470, CP570 via RayNet Radar Yes - Quantum, Digital, HD Color and Super HD Color Radars AIS Yes - N2K compatible GNSS / GPS Built-in GNSS Receiver: GPS/GLONASS/Galileo/Beidou - 10Hz 72 Channel - External Accessory: GA150 (A80288) Autopilot Control Yes - Evolution Autopilot Thermal Night Vision Yes - IP or Analogue Video / Camera 1 x Analogue input (BNC) Up to 10 IP Cameras Weather GRIB View - Free GRIB viewer and Theyr Ltd Subscription - SiriusXM - N. America Only Audio N2K / *Bluetooth / *SiriusXM Audio [*Available in future Lighthouse 3 software update] Digital Switching Yes - Empirbus & C-Zone compatible [C-Zone integration available in future Lighthouse 3 software update] Remote Control RMK-10 (A80438) & RCU-3 (E62351) Networking Ethernet 2 x 10/100/1000 Mbits/ Network (RayNet) NMEA0183 1 Transmit / 2 Receive NMEA2000 1 x NMEA2000 port (DeviceNet microC) SeaTalkNG Requires DEVICENET FEMALE (F) ADAPTOR CABLE (A06079 100mm adaptor included in box) USB 1 x USB microAB (rear - charging, external storage device or RCR-SD/USB Accessory (A80440) Wi-Fi WiFi - 802.11 a / b / g / n BlueTooth Bluetooth 4.0 + Low Energy + Power Class 1.5 [Available in future Lighthouse 3 software update] Navigation Cartography Lighthouse, Navionics, *C-MAP Essentials & *C-MAP 4D MAX+ [*C-MAP chart compatibility available in future Lighthouse 3 software update] Waypoint/Routes/Tracks (Wpts/Rts/Trk) 10,000 wpts / 200 wpt groups / 150 rts - 250 wpt max / 16 tracks - 10,000 max trk pts MEMORY Internal 16GB Solid State 16GB Solid State 2 x microSD slots (front) - microSDHC max 32GB NTFS or FAT32 format / microSDXC max 2TB NTFS or FAT32 format (microSD native format of exFAT must be reformatted to NTFS or FAT32) Input Voltage 12V and 24V DC (8 V to 32 DC) Input Draw ~45W Dimensions 17.8" x 10.2" x2.72" (452 x 258 x 69 mm) What's in the Box: Axiom Pro 16S Trim Kit Suncover Trunnion Kit PWR/VIDEO/NMEA0183 CBL, STRT 1.5M Mounting Hardware Mounting Template Quick Start Guide Warranty Card Raymarine window decal Lighthouse NC3 North America Lakes and Coastal Tide Stations microUSB Normalized SKU: E7048300102UPC Code: 723193838235

Raymarine E70483R ChartplottersRaymarine Axiom Pro 16S 15.6" MFD With Single Channel CHIRP - RemanufacturedModel: E70483R High CHIRP NMEA2000 & NMEA0183 Sonar Scroll Back HybridTouch™ Quad Core Processor Optical Bonding Technology & IPS Displays IP & Analog Video Clear Cruise™ Quantum CHIRP, HD & SHD NMEA2000 & NMEA0183 Specifications Display Size 15.6" IPS Optically Bonded LCD Display Resolution 1920 x 1080 FHD Display Type Multitouch Brightness 1,200 nits Viewing Angle Degrees: 88 / 88 / 88 / 88 (Top / Bottom / Left / Right) Mounting Top, Front, and optional RAM ball mount adapter Waterproof Rating IPX6 / IPX7 Operating Temp minus 13deg F to 131deg F (-25deg C to +55deg C) Storage Temp minus 22deg F to 158deg F (-30deg C to +70deg C) Sensors Sonar Type - Built-in High CHIRP Sonar Connections 25pin connector used only with CPT-S transducers, Pro S can only be used with CPT-S transducers that also connect directly to CP470 sonar module. Requires A80490 adaptor cable. Sonar Depth CHIRP Sonar = 900 feet (974 m)DownVision™ = 600 feet (183 m) External Sonar Yes - CP100, CP200, CP370, CP470, CP570 via RayNet Radar Yes - Quantum, Digital, HD Color and Super HD Color Radars AIS Yes - N2K compatible GNSS / GPS Built-in GNSS Receiver: GPS/GLONASS/Galileo/Beidou - 10Hz 72 Channel - External Accessory: GA150 (A80288) Autopilot Control Yes - Evolution Autopilot Thermal Night Vision Yes - IP or Analogue Video / Camera 1 x Analogue input (BNC) Up to 10 IP Cameras Weather GRIB View - Free GRIB viewer and Theyr Ltd Subscription - SiriusXM - N. America Only Audio N2K / *Bluetooth / *SiriusXM Audio [*Available in future Lighthouse 3 software update] Digital Switching Yes - Empirbus & C-Zone compatible [C-Zone integration available in future Lighthouse 3 software update] Remote Control RMK-10 (A80438) & RCU-3 (E62351) Networking Ethernet 2 x 10/100/1000 Mbits/ Network (RayNet) NMEA0183 1 Transmit / 2 Receive NMEA2000 1 x NMEA2000 port (DeviceNet microC) SeaTalkNG Requires DEVICENET FEMALE (F) ADAPTOR CABLE (A06079 100mm adaptor included in box) USB 1 x USB microAB (rear - charging, external storage device or RCR-SD/USB Accessory (A80440) Wi-Fi WiFi - 802.11 a / b / g / n BlueTooth Bluetooth 4.0 + Low Energy + Power Class 1.5 [Available in future Lighthouse 3 software update] Navigation Cartography Lighthouse, Navionics, *C-MAP Essentials & *C-MAP 4D MAX+ [*C-MAP chart compatibility available in future Lighthouse 3 software update] Waypoint/Routes/Tracks (Wpts/Rts/Trk) 10,000 wpts / 200 wpt groups / 150 rts - 250 wpt max / 16 tracks - 10,000 max trk pts MEMORY Internal 16GB Solid State 16GB Solid State 2 x microSD slots (front) - microSDHC max 32GB NTFS or FAT32 format / microSDXC max 2TB NTFS or FAT32 format (microSD native format of exFAT must be reformatted to NTFS or FAT32) Input Voltage 12V and 24V DC (8 V to 32 DC) Input Draw ~45W Dimensions 17.8" x 10.2" x2.72" (452 x 258 x 69 mm) What's in the Box: Axiom Pro 16S - Remanufactured Trim Kit Suncover Trunnion Kit PWR/VIDEO/NMEA0183 CBL, STRT 1.5M Mounting Hardware Mounting Template Quick Start Guide Warranty Card Raymarine window decal Normalized SKU: E70483R

Raymarine E70371-00-102 ChartplottersRaymarine Axiom Pro 9RVX 9" MFD With RealVision 3D and 1kW CHIRP, Lighthouse NC2 North America Lakes and Coastal Tide StationsModel: E70371-00-102 RealVision 3D True 1kW Sonar Sonar Scroll Back HybridTouch™ Quad Core Processor Optical Bonding Technology & IPS Displays IP & Analog Video Clear Cruise™ Quantum CHIRP, HD & SHD NMEA2000 & NMEA0183 Specifications Display Size 9" IPS Optically Bonded LCD Display Resolution 1280 x 720 WXGA Display Type Multitouch Brightness 1,200 nits Viewing Angle Degrees: 88 / 88 / 88 / 88 (Top / Bottom / Left / Right) Mounting Top, Front, Bracket Waterproof Rating IPX6 / IPX7 Operating Temp minus 13deg F to 131deg F (-25deg C to +55deg C) Storage Temp minus 22deg F to 158deg F (-30deg C to +70deg C) Sensors Sonar Type - Built-in RealVision 3D & 1kW CHIRP Sonar built in Sonar Connections 25pin connector used only with CPT-S transducers, Pro S can only be used with CPT-S transducers that also connect directly to CP470 sonar module. Requires A80490 adaptor cable. Sonar Depth CHIRP Sonar = 900 feet (974 m)DownVision™ = 600 feet (183 m) External Sonar Yes - CP100, CP200, CP370, CP470, CP570 via RayNet Radar Yes - Quantum, Digital, HD Color and Super HD Color Radars AIS Yes - N2K compatible GNSS / GPS Built-in GNSS Receiver: GPS/GLONASS/Galileo/Beidou - 10Hz 72 Channel - External Accessory: GA150 (A80288) Autopilot Control Yes - Evolution Autopilot Thermal Night Vision Yes - IP or Analogue Video / Camera 1 x Analogue input (BNC) Up to 10 IP Cameras Weather GRIB View - Free GRIB viewer and Theyr Ltd Subscription - SiriusXM - N. America Only Audio N2K / *Bluetooth / *SiriusXM Audio [*Available in future Lighthouse 3 software update] Digital Switching Yes - Empirbus & C-Zone compatible [C-Zone integration available in future Lighthouse 3 software update] Remote Control RMK-10 (A80438) & RCU-3 (E62351) Networking Ethernet 2 x 10/100/1000 Mbits/ Network (RayNet) NMEA0183 1 Transmit / 2 Receive NMEA2000 1 x NMEA2000 port (DeviceNet microC) SeaTalkNG Requires DEVICENET FEMALE (F) ADAPTOR CABLE (A06079 100mm adaptor included in box) USB 1 x USB microAB (rear - charging, external storage device or RCR-SD/USB Accessory (A80440) Wi-Fi WiFi - 802.11 a / b / g / n BlueTooth Bluetooth 4.0 + Low Energy + Power Class 1.5 [Available in future Lighthouse 3 software update] Navigation Cartography Lighthouse, Navionics, *C-MAP Essentials & *C-MAP 4D MAX+ [*C-MAP chart compatibility available in future Lighthouse 3 software update] Waypoint/Routes/Tracks (Wpts/Rts/Trk) 10,000 wpts / 200 wpt groups / 150 rts - 250 wpt max / 16 tracks - 10,000 max trk pts MEMORY Internal 16GB Solid State 16GB Solid State 2 x microSD slots (front) - microSDHC max 32GB NTFS or FAT32 format / microSDXC max 2TB NTFS or FAT32 format (microSD native format of exFAT must be reformatted to NTFS or FAT32) Input Voltage 12V and 24V DC (8 V to 32 DC) Input Draw ~20W Dimensions 11.9" x 6.85" x 2.56" (300 x 174 x 65 mm) What's in the Box: Axiom Pro 9RVX RayNet (F) to Raynet (F) Cable — 2M (A62361) Trunnion Cover Trunnion Knobs Trunnion Bracket Suncover (A80534) Power / Video / NMEA0183 Cable - Straight, 1.5M (R62379) Micro-C DeviceNet (F) to STNG (F) Cable - 1M (A06075) Panel Seal Gasket Bezel Pieces and Home / Menu Button Mounting Fixings Quick Start Guide Warranty Card Raymarine window decal Lighthouse NC3 Card Normalized SKU: E7037100102UPC Code: 723193838174

Raymarine E70481-00-102 ChartplottersRaymarine Axiom Pro 9S 9" MFD With Single Channel CHIRP and Lighthouse NC3 North America Lakes and Coastal Tide StationsModel: E70481-00-102 High CHIRP NMEA2000 & NMEA0183 Sonar Scroll Back HybridTouch™ Quad Core Processor Optical Bonding Technology & IPS Displays IP & Analog Video Clear Cruise™ Quantum CHIRP, HD & SHD Specifications Display Size 9" IPS Optically Bonded LCD Display Resolution 1280 x 720 WXGA Display Type Multitouch Brightness 1,200 nits Viewing Angle Degrees: 88 / 88 / 88 / 88 (Top / Bottom / Left / Right) Mounting Top, Front, Bracket Waterproof Rating IPX6 / IPX7 Operating Temp minus 13deg F to 131deg F (-25deg C to +55deg C) Storage Temp minus 22deg F to 158deg F (-30deg C to +70deg C) Sensors Sonar Type - Built-in High CHIRP Sonar Connections 25pin connector used only with CPT-S transducers, Pro S can only be used with CPT-S transducers that also connect directly to CP470 sonar module. Requires A80490 adaptor cable. Sonar Depth CHIRP Sonar = 900 feet (974 m)DownVision™ = 600 feet (183 m) External Sonar Yes - CP100, CP200, CP370, CP470, CP570 via RayNet Radar Yes - Quantum, Digital, HD Color and Super HD Color Radars AIS Yes - N2K compatible GNSS / GPS Built-in GNSS Receiver: GPS/GLONASS/Galileo/Beidou - 10Hz 72 Channel - External Accessory: GA150 (A80288) Autopilot Control Yes - Evolution Autopilot Thermal Night Vision Yes - IP or Analogue Video / Camera 1 x Analogue input (BNC) Up to 10 IP Cameras Weather GRIB View - Free GRIB viewer and Theyr Ltd Subscription - SiriusXM - N. America Only Audio N2K / *Bluetooth / *SiriusXM Audio [*Available in future Lighthouse 3 software update] Digital Switching Yes - Empirbus & C-Zone compatible [C-Zone integration available in future Lighthouse 3 software update] Remote Control RMK-10 (A80438) & RCU-3 (E62351) Networking Ethernet 2 x 10/100/1000 Mbits/ Network (RayNet) NMEA0183 1 Transmit / 2 Receive NMEA2000 1 x NMEA2000 port (DeviceNet microC) SeaTalkNG Requires DEVICENET FEMALE (F) ADAPTOR CABLE (A06079 100mm adaptor included in box) USB 1 x USB microAB (rear - charging, external storage device or RCR-SD/USB Accessory (A80440) Wi-Fi WiFi - 802.11 a / b / g / n BlueTooth Bluetooth 4.0 + Low Energy + Power Class 1.5 [Available in future Lighthouse 3 software update] Navigation Cartography Lighthouse, Navionics, *C-MAP Essentials & *C-MAP 4D MAX+ [*C-MAP chart compatibility available in future Lighthouse 3 software update] Waypoint/Routes/Tracks (Wpts/Rts/Trk) 10,000 wpts / 200 wpt groups / 150 rts - 250 wpt max / 16 tracks - 10,000 max trk pts MEMORY Internal 16GB Solid State 16GB Solid State 2 x microSD slots (front) - microSDHC max 32GB NTFS or FAT32 format / microSDXC max 2TB NTFS or FAT32 format (microSD native format of exFAT must be reformatted to NTFS or FAT32) Input Voltage 12V and 24V DC (8 V to 32 DC) Input Draw ~20W Dimensions 11.9" x 6.85" x 2.56" (300 x 174 x 65 mm) What's in the Box: Axiom Pro 9S RayNet (F) to Raynet (F) Cable — 2M (A62361) Trunnion Cover Trunnion Knobs Trunnion Bracket Suncover (A80534) Power / Video / NMEA0183 Cable - Straight, 1.5M (R62379) Micro-C DeviceNet (F) to STNG (F) Cable - 1M (A06075) Panel Seal Gasket Bezel Pieces and Home / Menu Button Lighthouse NC3 North America Lakes and Coastal Tide Stations microSD Mounting Fixings Quick Start Guide Warranty Card Raymarine window decal Normalized SKU: E7048100102UPC Code: 723193838150

Raymarine E70399R ChartplottersRaymarine Axiom XL 16 MFD OnlyRemanufacturedModel: E70399The Axiom XL range is the pinnacle of Raymarine navigation and modern helm integration.Designed for glass bridge installations, Axiom XL displays offer superior performance, large format visibility and elegant simplicity. Engineered to perform in extreme conditions, the fully waterproof Axiom XL family of glass bridge MFDS can be installed in both open cockpits and enclosed bridge stations. Each model uses in-plane switching technology (IPS) and Raymarine optical bonding to deliver wider viewing angles, sharp contrast, and unmatched readability in bright sun.Axiom XL’s edge-to-edge glass construction gives vessel designers the ability to create integrated and elegant navigation helm appearance.Specifications General Specifications Display Size 15.6" Display Type IPS (In-Plane Switching) Color Depth 24 bit Display Resolution 1920 x 1080 FHD Display Aspect Ratio 16:9 Viewing Angle Top 88’ / Bottom 88’ / Left 88’ / Right 88’ Power Nominal supply voltage 12 / 24 Vdc Operating voltage range 8 Vdc to 32 Vdc Fuse Requirements Inline fuse = 15Amp, or Thermal breaker = 15Amp Max. Power 60W Environmental Operating Temperature Range -25°C to + 55°C Storage temperature range -30°C to +70°C Humidity Up to 93% @40°C Water Ingress Protection IPx6 and IPx7 Physical Overall Dimensions W x D x H (mm) 395 x 78 x 249 Product Weight (Kg) 5.9 Other Specifications 64 GB Solid State (62 GB usable) Internal Storage What's in the Box: Axiom XL MFD Suncover (Silicone) Rear mounting bar x2 Documentation pack Mounting gasket tape Power / Video / NMEA 0183 cable. 1.5m (4.92ft) right-angled Mounting bar fixings x4 (M5 x20) Mounting fixings x4 (Including M5 bolts x35, M5 wavy washers, M5 nuts and mounting feet) SeaTalkng to DeviceNet 1m (3.3ft) adapter cable M3 screw x5, M3 spring washer and M3 crimp terminal (for optional grounding connection) RayNet 2m (6.6ft) network cable Normalized SKU: E70399RUPC Code: 723193835630

Raymarine E70399RNAVBNDL ChartplottersRaymarine Axiom XL 16 MFD Only Remanufactured with Navionics, GA150 and RCR1Model: E70399RNAVBNDLThe Axiom XL range is the pinnacle of Raymarine navigation and modern helm integration.Designed for glass bridge installations, Axiom XL displays offer superior performance, large format visibility and elegant simplicity. Engineered to perform in extreme conditions, the fully waterproof Axiom XL family of glass bridge MFDS can be installed in both open cockpits and enclosed bridge stations. Each model uses in-plane switching technology (IPS) and Raymarine optical bonding to deliver wider viewing angles, sharp contrast, and unmatched readability in bright sun.Axiom XL’s edge-to-edge glass construction gives vessel designers the ability to create integrated and elegant navigation helm appearance.Specifications General Specifications Display Size 15.6" Display Type IPS (In-Plane Switching) Color Depth 24 bit Display Resolution 1920 x 1080 FHD Display Aspect Ratio 16:9 Viewing Angle Top 88’ / Bottom 88’ / Left 88’ / Right 88’ Power Nominal supply voltage 12 / 24 Vdc Operating voltage range 8 Vdc to 32 Vdc Fuse Requirements Inline fuse = 15Amp, or Thermal breaker = 15Amp Max. Power 60W Environmental Operating Temperature Range -25°C to + 55°C Storage temperature range -30°C to +70°C Humidity Up to 93% @40°C Water Ingress Protection IPx6 and IPx7 Physical Overall Dimensions W x D x H (mm) 395 x 78 x 249 Product Weight (Kg) 5.9 Other Specifications 64 GB Solid State (62 GB usable) Internal Storage What's in the Box: Axiom XL MFD Suncover (Silicone) Rear mounting bar x2 Documentation pack Mounting gasket tape Power / Video / NMEA 0183 cable. 1.5m (4.92ft) right-angled Mounting bar fixings x4 (M5 x20) Mounting fixings x4 (Including M5 bolts x35, M5 wavy washers, M5 nuts and mounting feet) SeaTalkng to DeviceNet 1m (3.3ft) adapter cable M3 screw x5, M3 spring washer and M3 crimp terminal (for optional grounding connection) RayNet 2m (6.6ft) network cable GA150 Antenna RCR1 Card Reader Navionics Navplus Normalized SKU: E70399RNAVBNDL

Raymarine E70400R ChartplottersRaymarine Axiom XL 19 Reman #E70400RNormalized SKU: E70400R

Raymarine E70634R Chartplotters Raymarine Axiom+ 7 7" Muilti-Function Display - Remanufactured Model: E70634R Fluid and fast chart redraw of LightHouse, Navionics, and C-MAP electronic charts. Powerful quad-core processor, plus increased onboard storage for personal data and apps. Smart and intuitive LightHouse 3 OS makes navigating easy. ClearCruise™ Augmented Reality-capable for smarter navigation decisions. Nano-coated, impact-resistant glass screen repels water, oil, and smudges for better viewing and accurate touch controls. IPS display technology delivers wider viewing angles and sharp contrast at twice the resolution of traditional displays. Network with multiple Axiom displays, radars, sonar, and more. Next-generation, high-performance 10 Hz GPS/GNSS receiver with 4X increased sensitivity for accurate positioning. The performance-tuned Axiom Plus is a new generation of award-winning Raymarine multifunction displays. Optimized for speed, Axiom Plus is equipped with a powerful quad-core processor for industry-leading responsiveness and speed, giving you the power to seamlessly redraw charts, navigate with augmented reality, and experience RealVision™ 3D sonar. New, higher resolution IPS displays deliver 25 percent more brightness and new day/night color palettes offer enhanced visibility in any lighting condition. Axiom Plus features the renowned LightHouse 3 OS, the most powerful and easy-to-use Raymarine MFD operating system to date. Specifications General Display Size 7.0 inch High Density IPS Display Resolution 1024 x 600 (WSVGA) Display Type Multitouch with HydroTough™ rugged hydrophobic coating Brightness 1,500 nits Viewing Angle 85° Top, Bottom, Left, Right Dimensions W x H x D (Excluding trunnion and cables) 7.92 x 5.24 x 3.0in Mounting Options Surface, Flush, Trunnion, (Front installation bracket available) Waterproof Rating IPX6 / IPX7 Operating Temperature Range -25°C to +55°C (-13°F to +131°F) Storage Temperature Range -30°C to +70°C (-22°F to +158°F) Power Voltage 12V DC (8V to 16V DC) Power Consumption (Full brightness) 7.34 Watts. RV Sonar version 9.84 Watts Sensors GNSS / GPS Built-in GNSS Receiver: GPS/GLONASS/Galileo/Beidou* - 10Hz 28 Channel *Future software update required Sonar Type (Built-in) None Sonar Connections NA Sonar Depth NA External Sonar Option Yes - CP100, CP200, CP370, CP470, CP570, RVX1000 via RayNet Radar Yes - Quantum, Digital, HD Colour / Super HD Colour and Magnum Radars AIS Yes - NMEA2000 compatible Autopilot Control Yes - Evolution Autopilot Thermal Night Vision Yes FLIR AX8, M232, M300 Series, M400, M500 Video / Camera Compatible with CAM210IP, CAM220IP (Up to 10 IP network cameras) Weather GRIB View - Free GRIB viewer and Theyr Ltd SubscriptionSiriusXM - N. America Only Audio NMEA2000 / Bluetooth speaker controls / Optional SiriusXM Audio Digital Switching Yes - Empirbus & C-Zone compatible Remote Control Yes Optional RMK-10 (A80438) Networking Ethernet 1 x 10/100 Mbit/s Network (RayNet) NMEA0183 No NMEA2000 NMEA2000 via DeviceNet port. SeaTalkng compatible using an optional adapter SeaTalkNG Requires DeviceNet Female (F) adaptor cable (A06079 120mm adaptor included in box) USB 1 x USB microAB Wi-Fi WiFi - 802.11 a/b/g/n BlueTooth Bluetooth v4.0 Navigation Cartography Lighthouse Charts, Navionics, and C-MAP compatible Waypoint/Routes/Tracks (Wpts/Rts/Trk) 10,000 wpts / 200 wpt groups / 150 rts - 250 wpt max / 16 tracks - 10,000 max trk pts Memory Internal Memory 16 GB Solid State External Memory 1x MicroSD Card Slot Languages 24 Conformances NMEA 2000 certificationEurope: 1999/5/ECAustralia and New Zealand: C-Tick, Compliance Level 2FCC 47CFR part 15Industry Canada RSS210 What's in the Box: Multifunction Display (supplied with Trunnion adaptor fitted) - Remanufactured Trunnion bracket Trunnion knobs x 2 Suncover — Trunnion mount Panel mount gasket for surface/flush mounting M5x58 Threaded studs x 4 M5 Thumb nuts x 4 Documentation pack DeviceNet to SeaTalkng ® adaptor cable 120 mm (4.7 in) Power/NMEA 2000 cable (with 1.5 m (4.92 ft) power lead and 0.5 m (1.64 ft) NMEA 2000 lead) Normalized SKU: E70634R

Raymarine E70635-00-102 ChartplottersRaymarine Axiom+ 7RV 7" Muilti-Function Display with RealVision Sonar - No Transducer, with Lighthouse North America ChartsModel: E70635-00-102 Fluid and fast chart redraw of LightHouse, Navionics, and C-MAP electronic charts. Powerful quad-core processor, plus increased onboard storage for personal data and apps. Smart and intuitive LightHouse 3 OS makes navigating easy. ClearCruise™ Augmented Reality-capable for smarter navigation decisions. Nano-coated, impact-resistant glass screen repels water, oil, and smudges for better viewing and accurate touch controls. IPS display technology delivers wider viewing angles and sharp contrast at twice the resolution of traditional displays. Network with multiple Axiom displays, radars, sonar, and more. Next-generation, high-performance 10 Hz GPS/GNSS receiver with 4X increased sensitivity for accurate positioning. The performance-tuned Axiom Plus is a new generation of award-winning Raymarine multifunction displays. Optimized for speed, Axiom Plus is equipped with a powerful quad-core processor for industry-leading responsiveness and speed, giving you the power to seamlessly redraw charts, navigate with augmented reality, and experience RealVision™ 3D sonar.New, higher resolution IPS displays deliver 25 percent more brightness and new day/night color palettes offer enhanced visibility in any lighting condition. Axiom Plus features the renowned LightHouse 3 OS, the most powerful and easy-to-use Raymarine MFD operating system to date.Specifications General Display Size 7.0 inch High Density IPS Display Resolution 1024 x 600 (WSVGA) Display Type Multitouch with HydroTough™ rugged hydrophobic coating Brightness 1,500 nits Viewing Angle 85° Top, Bottom, Left, Right Dimensions W x H x D (Excluding trunnion and cables) 7.92 x 5.24 x 3.0in Mounting Options Surface, Flush, Trunnion, (Front installation bracket available) Waterproof Rating IPX6 / IPX7 Operating Temperature Range -25°C to +55°C (-13°F to +131°F) Storage Temperature Range -30°C to +70°C (-22°F to +158°F) Power Voltage 12V DC (8V to 16V DC) Power Consumption (Full brightness) 7.34 Watts. RV Sonar version 9.84 Watts Sensors GNSS / GPS Built-in GNSS Receiver: GPS/GLONASS/Galileo/Beidou* - 10Hz 28 Channel *Future software update required Sonar Type (Built-in) RV Version equipped with High CHIRP, DownVision, SideVision and RealVision 3D Sonar Connections 25pin RealVision™ type connector Sonar Depth High CHIRP Sonar = 900 feet (274m)DownVision™ = 600 feet (183m)SideVision™ = 300 feet (91m)RealVision™ 3D = 300 feet (91m) External Sonar Option Yes - CP100, CP200, CP370, CP470, CP570, RVX1000 via RayNet Radar Yes - Quantum, Digital, HD Colour / Super HD Colour and Magnum Radars AIS Yes - NMEA2000 compatible Autopilot Control Yes - Evolution Autopilot Thermal Night Vision Yes FLIR AX8, M232, M300 Series, M400, M500 Video / Camera Compatible with CAM210IP, CAM220IP (Up to 10 IP network cameras) Weather GRIB View - Free GRIB viewer and Theyr Ltd SubscriptionSiriusXM - N. America Only Audio NMEA2000 / Bluetooth speaker controls / Optional SiriusXM Audio Digital Switching Yes - Empirbus & C-Zone compatible Remote Control Yes Optional RMK-10 (A80438) Networking Ethernet 1 x 10/100 Mbit/s Network (RayNet) NMEA0183 No NMEA2000 NMEA2000 via DeviceNet port. SeaTalkng compatible using an optional adapter SeaTalkNG Requires DeviceNet Female (F) adaptor cable (A06079 120mm adaptor included in box) USB 1 x USB microAB Wi-Fi WiFi - 802.11 a/b/g/n BlueTooth Bluetooth v4.0 Navigation Cartography Lighthouse Charts, Navionics, and C-MAP compatible Waypoint/Routes/Tracks (Wpts/Rts/Trk) 10,000 wpts / 200 wpt groups / 150 rts - 250 wpt max / 16 tracks - 10,000 max trk pts Memory Internal Memory 16 GB Solid State External Memory 1x MicroSD Card Slot Languages 24 Conformances NMEA 2000 certificationEurope: 1999/5/ECAustralia and New Zealand: C-Tick, Compliance Level 2FCC 47CFR part 15Industry Canada RSS210 What's in the Box: Multifunction Display (supplied with Trunnion adaptor fitted) Trunnion bracket Trunnion knobs x 2 Suncover — Trunnion mount Panel mount gasket for surface/flush mounting M5x58 Threaded studs x 4 M5 Thumb nuts x 4 Documentation pack DeviceNet to SeaTalkng ® adaptor cable 120 mm (4.7 in) Power/NMEA 2000 cable (with 1.5 m (4.92 ft) power lead and 0.5 m (1.64 ft) NMEA 2000 lead) Lighthouse North America mSD Chart Card Normalized SKU: E7063500102UPC Code: 723193837948

Raymarine E70635-03-102 ChartplottersRaymarine Axiom+ 7RV 7" Muilti-Function Display with RealVision Sonar - No Transducer, with Lighthouse North America Charts and RV100 TransducerModel: E70635-03-102 Fluid and fast chart redraw of LightHouse, Navionics, and C-MAP electronic charts. Powerful quad-core processor, plus increased onboard storage for personal data and apps. Smart and intuitive LightHouse 3 OS makes navigating easy. ClearCruise™ Augmented Reality-capable for smarter navigation decisions. Nano-coated, impact-resistant glass screen repels water, oil, and smudges for better viewing and accurate touch controls. IPS display technology delivers wider viewing angles and sharp contrast at twice the resolution of traditional displays. Network with multiple Axiom displays, radars, sonar, and more. Next-generation, high-performance 10 Hz GPS/GNSS receiver with 4X increased sensitivity for accurate positioning. The performance-tuned Axiom Plus is a new generation of award-winning Raymarine multifunction displays. Optimized for speed, Axiom Plus is equipped with a powerful quad-core processor for industry-leading responsiveness and speed, giving you the power to seamlessly redraw charts, navigate with augmented reality, and experience RealVision™ 3D sonar.New, higher resolution IPS displays deliver 25 percent more brightness and new day/night color palettes offer enhanced visibility in any lighting condition. Axiom Plus features the renowned LightHouse 3 OS, the most powerful and easy-to-use Raymarine MFD operating system to date.Specifications General Display Size 7.0 inch High Density IPS Display Resolution 1024 x 600 (WSVGA) Display Type Multitouch with HydroTough™ rugged hydrophobic coating Brightness 1,500 nits Viewing Angle 85° Top, Bottom, Left, Right Dimensions W x H x D (Excluding trunnion and cables) 7.92 x 5.24 x 3.0in Mounting Options Surface, Flush, Trunnion, (Front installation bracket available) Waterproof Rating IPX6 / IPX7 Operating Temperature Range -25°C to +55°C (-13°F to +131°F) Storage Temperature Range -30°C to +70°C (-22°F to +158°F) Power Voltage 12V DC (8V to 16V DC) Power Consumption (Full brightness) 7.34 Watts. RV Sonar version 9.84 Watts Sensors GNSS / GPS Built-in GNSS Receiver: GPS/GLONASS/Galileo/Beidou* - 10Hz 28 Channel *Future software update required Sonar Type (Built-in) RV Version equipped with High CHIRP, DownVision, SideVision and RealVision 3D Sonar Connections 25pin RealVision™ type connector Sonar Depth High CHIRP Sonar = 900 feet (274m)DownVision™ = 600 feet (183m)SideVision™ = 300 feet (91m)RealVision™ 3D = 300 feet (91m) External Sonar Option Yes - CP100, CP200, CP370, CP470, CP570, RVX1000 via RayNet Radar Yes - Quantum, Digital, HD Colour / Super HD Colour and Magnum Radars AIS Yes - NMEA2000 compatible Autopilot Control Yes - Evolution Autopilot Thermal Night Vision Yes FLIR AX8, M232, M300 Series, M400, M500 Video / Camera Compatible with CAM210IP, CAM220IP (Up to 10 IP network cameras) Weather GRIB View - Free GRIB viewer and Theyr Ltd SubscriptionSiriusXM - N. America Only Audio NMEA2000 / Bluetooth speaker controls / Optional SiriusXM Audio Digital Switching Yes - Empirbus & C-Zone compatible Remote Control Yes Optional RMK-10 (A80438) Networking Ethernet 1 x 10/100 Mbit/s Network (RayNet) NMEA0183 No NMEA2000 NMEA2000 via DeviceNet port. SeaTalkng compatible using an optional adapter SeaTalkNG Requires DeviceNet Female (F) adaptor cable (A06079 120mm adaptor included in box) USB 1 x USB microAB Wi-Fi WiFi - 802.11 a/b/g/n BlueTooth Bluetooth v4.0 Navigation Cartography Lighthouse Charts, Navionics, and C-MAP compatible Waypoint/Routes/Tracks (Wpts/Rts/Trk) 10,000 wpts / 200 wpt groups / 150 rts - 250 wpt max / 16 tracks - 10,000 max trk pts Memory Internal Memory 16 GB Solid State External Memory 1x MicroSD Card Slot Languages 24 Conformances NMEA 2000 certificationEurope: 1999/5/ECAustralia and New Zealand: C-Tick, Compliance Level 2FCC 47CFR part 15Industry Canada RSS210 What's in the Box: Multifunction Display (supplied with Trunnion adaptor fitted) Trunnion bracket Trunnion knobs x 2 Suncover — Trunnion mount Panel mount gasket for surface/flush mounting M5x58 Threaded studs x 4 M5 Thumb nuts x 4 Documentation pack DeviceNet to SeaTalkng ® adaptor cable 120 mm (4.7 in) Power/NMEA 2000 cable (with 1.5 m (4.92 ft) power lead and 0.5 m (1.64 ft) NMEA 2000 lead) Lighthouse North America mSD Chart Card RV100 Transducer Normalized SKU: E7063503102UPC Code: 723193839492

Raymarine E70637-00-102 ChartplottersRaymarine Axiom+ 9RV 9" Muilti-Function Display with RealVision Sonar - No Transducer and Lighthouse North America ChartsModel: E70637-00-102 Fluid and fast chart redraw of LightHouse, Navionics, and C-MAP electronic charts. Powerful quad-core processor, plus increased onboard storage for personal data and apps. Smart and intuitive LightHouse 3 OS makes navigating easy. ClearCruise™ Augmented Reality-capable for smarter navigation decisions. Nano-coated, impact-resistant glass screen repels water, oil, and smudges for better viewing and accurate touch controls. IPS display technology delivers wider viewing angles and sharp contrast at twice the resolution of traditional displays. Network with multiple Axiom displays, radars, sonar, and more. Next-generation, high-performance 10 Hz GPS/GNSS receiver with 4X increased sensitivity for accurate positioning. The performance-tuned Axiom Plus is a new generation of award-winning Raymarine multifunction displays. Optimized for speed, Axiom Plus is equipped with a powerful quad-core processor for industry-leading responsiveness and speed, giving you the power to seamlessly redraw charts, navigate with augmented reality, and experience RealVision™ 3D sonar.New, higher resolution IPS displays deliver 25 percent more brightness and new day/night color palettes offer enhanced visibility in any lighting condition. Axiom Plus features the renowned LightHouse 3 OS, the most powerful and easy-to-use Raymarine MFD operating system to date.Specifications General Display Size 9.0 inch High Density IPS Display Resolution 1280 x 720 (WXGA) Display Type Multitouch with HydroTough™ rugged hydrophobic coating Brightness 1,500 nits Viewing Angle 85° Top, Bottom, Left, Right Dimensions W x H x D (Excluding trunnion and cables) 9.65 x 6.22 x 3.0in Mounting Options Surface, Flush, Trunnion, (Front installation bracket available) Waterproof Rating IPX6 / IPX7 Operating Temperature Range -25°C to +55°C (-13°F to +131°F) Storage Temperature Range -30°C to +70°C (-22°F to +158°F) Power Voltage 12V DC (8V to 16V DC) Power Consumption (Full brightness) 11.98 Watts Sensors GNSS / GPS Built-in GNSS Receiver: GPS/GLONASS/Galileo/Beidou* - 10Hz 28 Channel *Future software update required Sonar Type (Built-in) RV Version equipped with High CHIRP, DownVision, SideVision and RealVision 3D Sonar Connections 25pin RealVision™ type connector Sonar Depth High CHIRP Sonar = 900 feet (274m)DownVision™ = 600 feet (183m)SideVision™ = 300 feet (91m)RealVision™ 3D = 300 feet (91m) External Sonar Option Yes - CP100, CP200, CP370, CP470, CP570, RVX1000 via RayNet Radar Yes - Quantum, Digital, HD Colour / Super HD Colour and Magnum Radars AIS Yes - NMEA2000 compatible Autopilot Control Yes - Evolution Autopilot Thermal Night Vision Yes FLIR AX8, M232, M300 Series, M400, M500 Video / Camera Compatible with CAM210IP, CAM220IP (Up to 10 IP network cameras) Weather GRIB View - Free GRIB viewer and Theyr Ltd SubscriptionSiriusXM - N. America Only Audio NMEA2000 / Bluetooth speaker controls / Optional SiriusXM Audio Digital Switching Yes - Empirbus & C-Zone compatible Remote Control Yes Optional RMK-10 (A80438) Networking Ethernet 1 x 10/100 Mbit/s Network (RayNet) NMEA0183 No NMEA2000 NMEA2000 via DeviceNet port. SeaTalkng compatible using an optional adapter SeaTalkNG Requires DeviceNet Female (F) adaptor cable (A06079 120mm adaptor included in box) USB 1 x USB microAB Wi-Fi WiFi - 802.11 a/b/g/n BlueTooth Bluetooth v4.0 Navigation Cartography Lighthouse Charts, Navionics, and C-MAP compatible Waypoint/Routes/Tracks (Wpts/Rts/Trk) 10,000 wpts / 200 wpt groups / 150 rts - 250 wpt max / 16 tracks - 10,000 max trk pts Memory Internal Memory 16 GB Solid State External Memory 1x MicroSD Card Slot Languages 24 Conformances NMEA 2000 certificationEurope: 1999/5/ECAustralia and New Zealand: C-Tick, Compliance Level 2FCC 47CFR part 15Industry Canada RSS210 What's in the Box: Multifunction Display Trunnion bracket Trunnion knobs x 2 Suncover — Trunnion mount Panel mount gasket for surface/flush mounting M5x58 Threaded studs x 4 M5 Thumb nuts x 4 Documentation pack DeviceNet to SeaTalkng ® adaptor cable 120 mm (4.7 in) Power/NMEA 2000 cable (with 1.5 m (4.92 ft) power lead and 0.5 m (1.64 ft) NMEA 2000 lead) Rear mounting brackets: Lighthouse North America Charts mSD Normalized SKU: E7063700102UPC Code: 723193838518

Raymarine E70637-03-102 ChartplottersRaymarine Axiom+ 9RV 9" Muilti-Function Display with RealVision Sonar - with RV100 Transducer and Lighthouse North America ChartsModel: E70637-03-102 Fluid and fast chart redraw of LightHouse, Navionics, and C-MAP electronic charts. Powerful quad-core processor, plus increased onboard storage for personal data and apps. Smart and intuitive LightHouse 3 OS makes navigating easy. ClearCruise™ Augmented Reality-capable for smarter navigation decisions. Nano-coated, impact-resistant glass screen repels water, oil, and smudges for better viewing and accurate touch controls. IPS display technology delivers wider viewing angles and sharp contrast at twice the resolution of traditional displays. Network with multiple Axiom displays, radars, sonar, and more. Next-generation, high-performance 10 Hz GPS/GNSS receiver with 4X increased sensitivity for accurate positioning. The performance-tuned Axiom Plus is a new generation of award-winning Raymarine multifunction displays. Optimized for speed, Axiom Plus is equipped with a powerful quad-core processor for industry-leading responsiveness and speed, giving you the power to seamlessly redraw charts, navigate with augmented reality, and experience RealVision™ 3D sonar.New, higher resolution IPS displays deliver 25 percent more brightness and new day/night color palettes offer enhanced visibility in any lighting condition. Axiom Plus features the renowned LightHouse 3 OS, the most powerful and easy-to-use Raymarine MFD operating system to date.Specifications General Display Size 9.0 inch High Density IPS Display Resolution 1280 x 720 (WXGA) Display Type Multitouch with HydroTough™ rugged hydrophobic coating Brightness 1,500 nits Viewing Angle 85° Top, Bottom, Left, Right Dimensions W x H x D (Excluding trunnion and cables) 9.65 x 6.22 x 3.0in Mounting Options Surface, Flush, Trunnion, (Front installation bracket available) Waterproof Rating IPX6 / IPX7 Operating Temperature Range -25°C to +55°C (-13°F to +131°F) Storage Temperature Range -30°C to +70°C (-22°F to +158°F) Power Voltage 12V DC (8V to 16V DC) Power Consumption (Full brightness) 11.98 Watts Sensors GNSS / GPS Built-in GNSS Receiver: GPS/GLONASS/Galileo/Beidou* - 10Hz 28 Channel *Future software update required Sonar Type (Built-in) RV Version equipped with High CHIRP, DownVision, SideVision and RealVision 3D Sonar Connections 25pin RealVision™ type connector Sonar Depth High CHIRP Sonar = 900 feet (274m)DownVision™ = 600 feet (183m)SideVision™ = 300 feet (91m)RealVision™ 3D = 300 feet (91m) External Sonar Option Yes - CP100, CP200, CP370, CP470, CP570, RVX1000 via RayNet Radar Yes - Quantum, Digital, HD Colour / Super HD Colour and Magnum Radars AIS Yes - NMEA2000 compatible Autopilot Control Yes - Evolution Autopilot Thermal Night Vision Yes FLIR AX8, M232, M300 Series, M400, M500 Video / Camera Compatible with CAM210IP, CAM220IP (Up to 10 IP network cameras) Weather GRIB View - Free GRIB viewer and Theyr Ltd SubscriptionSiriusXM - N. America Only Audio NMEA2000 / Bluetooth speaker controls / Optional SiriusXM Audio Digital Switching Yes - Empirbus & C-Zone compatible Remote Control Yes Optional RMK-10 (A80438) Networking Ethernet 1 x 10/100 Mbit/s Network (RayNet) NMEA0183 No NMEA2000 NMEA2000 via DeviceNet port. SeaTalkng compatible using an optional adapter SeaTalkNG Requires DeviceNet Female (F) adaptor cable (A06079 120mm adaptor included in box) USB 1 x USB microAB Wi-Fi WiFi - 802.11 a/b/g/n BlueTooth Bluetooth v4.0 Navigation Cartography Lighthouse Charts, Navionics, and C-MAP compatible Waypoint/Routes/Tracks (Wpts/Rts/Trk) 10,000 wpts / 200 wpt groups / 150 rts - 250 wpt max / 16 tracks - 10,000 max trk pts Memory Internal Memory 16 GB Solid State External Memory 1x MicroSD Card Slot Languages 24 Conformances NMEA 2000 certificationEurope: 1999/5/ECAustralia and New Zealand: C-Tick, Compliance Level 2FCC 47CFR part 15Industry Canada RSS210 What's in the Box: Multifunction Display Trunnion bracket Trunnion knobs x 2 Suncover — Trunnion mount Panel mount gasket for surface/flush mounting M5x58 Threaded studs x 4 M5 Thumb nuts x 4 Documentation pack DeviceNet to SeaTalkng ® adaptor cable 120 mm (4.7 in) Power/NMEA 2000 cable (with 1.5 m (4.92 ft) power lead and 0.5 m (1.64 ft) NMEA 2000 lead) Rear mounting brackets: Lighthouse North America Charts mSD RV100 Transducer Normalized SKU: E7063703102UPC Code: 723193839614
